Research and Design for the Calibrating Device of Self-Propelled Artillery’s Center Line

Abstract:

Center line correction is an important work in the assembly and maintenance of self-propelled artillery. Targeting the complexity of centerline correction and low accuracy, a self-propelled artillery center line correction apparatus was developed on the basis of DSP technology. The device can directly display the thickness of the measured components that needed to be modified and adjusted. The measurement works in a simple and convenient manner, which greatly improve the measuring precision, and significantly accelerate the assembly and repair schedule. Through a simple transformation the correction device can be applied to the assembly and maintenance of other vehicles, featuring strong versatility and wide range of trial.
