Integration of Piezoceramic Tube under Prestress into a Load Carrying Structure

Abstract:

Smart structures consisting of a load carrying structure and smart materials with actuatory and sensory capabilities feature high potential in numerous applications. However, to master the assembly conditions of smart structures, there is a need to integrate additional design parameters such as prestress of the smart material, critical loads and electric contacting as well as insulation into the process development. This paper focusses on the design of an incremental bulk forming process to integrate piezoceramic components into an aluminum tube simultaneously to the manufacturing process. Axial forces imposed on the piezoceramic are investigated numerically and experimentally to verify the design of critical components and the process control. Within this investigation, in situ measurement of the direct piezoelectric effect provides a method to validate the numerical design with regard to failure of the piezo tube and the functional properties of the overall structure.

• Periodical: Advanced Materials Research (Volumes 966-967)
• Pages: 651-658
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.966-967.651
• Online since: June 2014
• Authors: Matthias Brenneis*, Peter Groche
• Keywords: In Situ Measurement, Joining by Forming, Residual Force

References

[1] European Commision, HORIZON 2020 Work Program 2014 – 2015, Leadership in enabling and industrial technologies.

[2] B. Denkena, H. Boujnah, H. Henning, T. Mörke, J. Schmidt, J. Meyer, Benefits of gentelligent components, wt online, 103 H2, 2013, pp.152-156.

[3] A. Belski, M.C. Wurz, J. Rittinger, L. Rissing, Development, micro fabrication, and test of flexible magnetic write head for gentelligent applications, Microelectron. Eng. 110 (2013) 315-319.

DOI: 10.1016/j.mee.2013.02.035

[4] Y. Lin, H.A. Sodano, Concept and model of a piezoelectric structural fiber for multifunctional composites, Compos. Sci. Technol. 68 7-8 (2008) 1911-(1918).

DOI: 10.1016/j.compscitech.2007.12.017

[5] A. Weder, S. Geller, A. Heinig, T. Tyczynski, W. Hufenbach, W. -J. Fischer, A novel technology for the high-volume production of intelligent composite structures with integrated piezoceramic sensors and electronic components, Sensor Actuat A-Phys (2013).

DOI: 10.1016/j.sna.2013.01.050

[6] K. Mori, N. Bay, L. Fratini, F. Micari, A.E. Tekkaya, Joining by plastic deformation, CIRP Ann. Manuf. Technol. 62 2 (2013) 673-694.

DOI: 10.1016/j.cirp.2013.05.004

[7] A. Schubert, V. Wittstock, S.F. Jahn, B. Müller, M. Müller: Joining by forming of piezoceramic macro-fiber arrays within micro-structured surfaces of aluminum sheets, Prod. Eng. Res. Devel. 1 11 (2013).

DOI: 10.1007/s11740-013-0498-7

[8] W.G. Drossel, S. Hensel, M. Nestler, L. Lachmann, A. Schubert, M. Müller, B. Müller, Experimental and numerical study on shaping of aluminum sheets with integrated piezoceramic fibers, J. Mater. Process. Technol. 214 2 (2014) 217-228.

DOI: 10.1016/j.jmatprotec.2013.08.011

[9] M. Brenneis, M. Ibis, A. Duschka, P. Groche, Towards Mass Production of Smart Products by Forming Technologies, to be published in Proc. of the 2nd WGP annual meeting, Berlin, Germany, June (2012).

DOI: 10.4028/www.scientific.net/amr.907.113

[10] P. Groche, M. Türk, Smart structures assembly through incremental forming, CIRP Annals 60 1 (2011) 21-24.

DOI: 10.1016/j.cirp.2011.03.003

[11] P. Groche, D. Fritsche, E.A. Tekkaya, J.M. Allwood, G. Hirt, R. Neugebauer, Incremental Bulk Metal Forming, CIRP Annals 56 2 (2007) 635-656.

DOI: 10.1016/j.cirp.2007.10.006

[12] M. Brenneis, P. Groche, Smart components through rotary swaging, Key Eng. Mater. 504-506 (2012) 723-728.

DOI: 10.4028/www.scientific.net/kem.504-506.723

[13] T. Rathmann, Entwicklung eines Technologieprozessors zur Untersuchung des Kaltrundknetens mit Hilfe der Finite Elemente Analyse (engl.: Development of a technology processor to investigate rotary swaging process using the finite element analysis), Phd Thesis, Darmstadt, (2006).
