Non-Linear Least Squares Large Misalignment Estimation in Transfer Alignment

Abstract:

Large misalignment is unavoidable for subsystems which could be deployed randomly on the carriers such as shipborne aircrafts, AUV. Ordinary linear filtering algorithms don’t converge fast and accurately in non-linear conditions. It's critical for the accuracy of the transfer alignment. In this paper, a new misalignment and gyroscope bias online estimation method based on angular velocity processing is presented. Sensor measurements of M-SINS and S-SINS will be recorded for a certain period. Misalignment and the gyroscope bias will be calculated from these measurements directly with non-linear least square algorithm. Trust region method with pre-conditioning, subspace and conjugate gradient are applied for faster converge and better accuracy. Simulation results demonstrate the effectiveness of the algorithm.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 1962-1968
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.1962
• Online since: July 2014
• Authors: Yuan Lu*, Xiang Hong Cheng
• Keywords: Estimation, Least Square (LS), Lever Arm, Misalignment, Statistic, Transfer Alignment

References

[1] Kain J E, Cloutier J R. Rapid Transfer Alignment for Tactical Weapon Applications[C], AIAA Guidance, Navigation and Control Conference. 1989. 1290～1300.

DOI: 10.2514/6.1989-3581

[2] K. Madsen, H.B. Nielsen,O. Tingleff, Methods For Non-Linear Least Squares Problems[M], Informatics and Mathematical Modelling, Technical University of Denmark, (2004).

[3] Vandenberhe L. Applied Numerical Computing[M], USA: UCLA, 2011. 207-211.

[4] Zhi-rong D. Nonlinear Least-Square Algorithms Used for TMA in Bearing-only System-The Engineering Mathematic Model and Algorithms [J]. Intelligence Command Control and Simulation Technigues, 2005, 2.

[5] D.C. Sorensen, Newton's Method With A Model Trust Region Modification[J], SIAM J. Numer. Anal., Vol. 19, No. 2, pp.409-426, (1982).

DOI: 10.1137/0719026

[6] Moré, J.J. and D.C. Sorensen, Computing a Trust Region Step[J], SIAM Journal on Scientific and Statistical Computing, Vol. 3, p.553–572, (1983).

DOI: 10.1137/0904038

[7] Y. Yuan. A review of trust region algorithms for optimization[C], in ICIAM 99: Proceedings of the Fourth International Congress on Industrial & Applied Mathematics, Edinburgh, (2000).

[8] Branch, M.A., T.F. Coleman, and Y. Li, A Subspace, Interior, and Conjugate Gradient Method for Large-Scale Bound-Constrained Minimization Problems[J], SIAM Journal on Scientific Computing, Vol. 21, Number 1, p.1–23, (1999).

DOI: 10.1137/s1064827595289108

[9] Byrd, R.H., R.B. Schnabel, and G.A. Shultz, Approximate Solution of the Trust Region Problem by Minimization over Two-Dimensional Subspaces[J], Mathematical Programming, Vol. 40, p.247–263, (1988).

DOI: 10.1007/bf01580735

[10] Coleman, T.F. and A. Verma, A Preconditioned Conjugate Gradient Approach to Linear Equality Constrained Minimization[J], Computational Optimization and Applications, Vol. 20, No. 1, p.61–72, (2001).

[11] Elena Caraba, Preconditioned Conjugate Gradient Algorithm[D], Louisiana State University & agricultural and mechanical College, (2008).

[12] Lu Yuan, Cheng Xianghong, Reference Information Time Delay Estimation and Compensation in Transfer Alignment[J], Journal of Southeast University(English Edition), 2011, 27(1): 52-55.
