Investigation of TSV Induced Thermo-Mechanical Stress: Implementation of Piezoresistive Sensors and Correlation with Simulation

Abstract:

This work deals with a methodology to evaluate residual stresses within microelectronic devices by using MOS (Metal Oxide Semiconductor) rosette stress sensors. The stress tensor was evaluated by carrying out electrical measurements on test vehicle: the bridge from electrical to stress values was ensured by the piezoresistive relations and, prior to further in-house calibration, coefficients from literature were employed. For correlation purpose, numerical simulations were performed in order to evaluate stresses induced by TSV (Through Silicon Via). In this paper, the whole framework is described, and stress fields evaluated from in-situ electrical measurements on CMOS65 rosette sensor are compared to simulated ones. Some of the ultimate targets of this work are to develop a validated framework to deeply understand TSV induced thermo-mechanical stresses and to allow design rules definitions for products reliability and transistor performances.

By email View Pdf

You have full access to the following eBook

Read eBook

Info:

Periodical:

Advanced Materials Research (Volume 996)

Pages:

975-981

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.996.975

Citation:

Cite this paper

Online since:

August 2014

Authors:

Komi Atchou Ewuame, Vincent Fiori, Karim Inal, Pierre-Olivier Bouchard, Sebastien Gallois-Garreignot, Sylvain Lionti, Clement Tavernier, Herve Jaouen

Keywords:

FEM Simulation, Piezoresistive Stress Sensor, Residual Stress, Thermomechanics, TSV

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0

Citation:

References

[1] International Technology Roadmap for Semiconductors (ITRS), (2010).

Google Scholar

[2] I. De Wolf, V. Simons, V. Cherman, R. Labie, B. Vandevelde, E. Beyne and IMEC, In-depth Raman Spectroscopy Analysis of Various Parameters Affecting the Mechanical Stress near the Surface and Bulk of Cu-TSVs, IEEE, 978-1-4673-1965-2, (2012).

DOI: 10.1109/ectc.2012.6248851

Google Scholar

[3] K. Aditya, X. Zhang, Q. X. Zhang, M. C. Jong, G. Huang, L. W. S. Vincent, C. Lee, J. H. Lau, D. L. Kwong, R. R. Tummula and G. Meyer-Berg, Residual Stress Analysis in Thin Device Wafer Using Piezoresistive Stress Sensor, IEEE Transactions on Components Packaging and Manufacturing Technology, vol. 1, p.6, (2011).

DOI: 10.1109/tcpmt.2011.2135353

Google Scholar

[4] X. Zhang, K. Aditya, Q. Zhanga, Y. Onga, S. Hoa, C. Khonga, V. Kripesha, J. Laua, D. -L. Kwonga, V. Sundaramb, R. Tummulab and G. Meyer-Berg, Application of Piezoresistive Stress Sensors in Ultra Thin Device Handling and Characterization, Sensors and Actuators A156, pp.2-7, (2009).

DOI: 10.1016/j.sna.2009.01.024

Google Scholar

[5] C. S. Smith, Piezoresistance effect in germanium and silicon, Phys. Rev., vol. 94, pp.42-49, (1954).

Google Scholar

[6] E. Roux, P-O. Bouchard, Kriging metamodel global optimization of clinching joining processes accounting for ductile damage, Journal of Materials Processsing Technology, 213(7): 1038-1047, (2013).

DOI: 10.1016/j.jmatprotec.2013.01.018

Google Scholar

[7] M. Gregoire, Properties of Thin Film and Copper Interconnects. Thesis in Science and Engineering of Materials. Grenoble : National Polytechnic Institute of Grenoble, 2006, 248 p.

Google Scholar
