Study on Forming Limit of Irregular Axial Holes Formed by Open-Die Cold Extrusion

Abstract:

The parts with axial special-hole, which are difficult to be processed by traditional machining process because of the high cost and low efficiency, are widely used in many fields. In this paper, a new practicable method to form axial special-hole by open-die cold extrusion is put forward. The four failure types of forming axial irregular-holes by open-die extrusion are analyzed. The key parameters, cone angle, reduction, original ratio of the thickness-diameter, etc., which largely influence forming process and the limits range is analyzed by numerical simulation , and make an experiment to verify the results. Based on the analysis, the law of shaping and the limit of the key parameters are concluded. The optimum range of the die’s cone angles is from 16° to 22°.The largest reduction is 24% for the billets with concave outer profile and 22% for the billets with convex outer profile.

• Periodical: Advanced Materials Research (Volume 997)
• Pages: 678-683
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.997.678
• Online since: August 2014
• Authors: Shuang Jie Zhang, Wen Hua Gu, Xue Rui Dai, Xin Xu, Jun Li
• Keywords: Axial Special-Hole, Forming Limit, Largest Reduction, Open-Die Cold Extrusion, Optimum Cone Angle

References

[1] Wu Zhen-ying, Forming principle of special hole boring, J. Mechanical process engineer. 1(1999)22-23.

[2] Zou Guo-lin, Lin Jian-xu, The feasibility analysis of laval nozzle applied to the complex rocket motor, J. Journal of North China Institute of Technology. 19( 1998)298-301.

[3] Lu Wei-zhong, The cause analysis of the Laval nozzle corroded used at 2RH vacuum system in Baostee, J. Vacuum. 1(2004) 57-61.

[4] K. Pianthong, S. Zakrzewski, M. Behnia, B.E. Milton, Characteristics of impact driven supersonic liquid jets. J. Experimental Thermal and Fluid Science. 27(2003)589-598.

DOI: 10.1016/s0894-1777(02)00273-x

[5] M.J. Jacksona, G.M. Robinsona, M.D.H. Gillb, W. O'Neillb, The effect of nozzle design on laser micro-machining of M2 tool steels,J. Journal of materials Processing Technology. 160 (2005) 198-212.

DOI: 10.1016/j.jmatprotec.2004.05.030

[6] Li Jun, Research on open-die cold extrusion forming's modelling and its technological parameters application, D. Tianjin China: Paper of doctoral degree tianjin university, (1997).

[7] Gu Wenhua, Study on shaping for open-die extrusion of axial special-hole, M. Shi jia-zhuang: Dissertation for the Master Degree in Engineering Hebei University of Science and Technology, (2006).

[8] Li Jun, Zhang Shuang-jie, Han Peng-biao, Research on the power and force of open-die cold extrusion, J. Journal of HeBei university of science and technology. 2(2000)17-21.

[9] Zhang Shuang-jie，Li Qiang，Wang Li-juan, Analysis on the forming limit of cold open-die extrusion with mandrel for the thick-walled tube,J. Journal of mechanical engineering. 22(2010)53-56.

DOI: 10.3901/jme.2010.22.053
