Natural Convection in a Non-Uniformly Heated Vertical Annular Cavity

Abstract:

Natural convection from the linearly heated inner and/or outer walls of a vertical annular cavity has been numerically investigated. The bottom wall is uniformly heated and top cylindrical wall is thermally insulated. In this analysis, we considered two different thermal boundary conditions, namely case (I) and case (II) to understand the effect of non-uniform heating of inner and/or outer walls on the convective flow and subsequently the local and global heat transfer rate. For case (I), the inner and outer walls are heated linearly, while the linearly heated inner wall and cooled outer wall is considered in case (II). An implicit finite difference scheme is applied to solve the model equations of the problem. The numerical simulations in terms of streamlines and isotherms, local and global Nusselt numbers are presented to illustrate the effects of Rayleigh number and non-uniform thermal boundary conditions for a fixed Prandtl number of Pr = 0.7.

• Periodical: Defect and Diffusion Forum (Volume 377)
• Pages: 189-199
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.377.189
• Online since: September 2017
• Authors: M. Sankar, S. Kiran, G.K. Ramesh*, Oluwole Daniel Makinde
• Keywords: Annulus, Convection, Finite Difference Method, Non-Uniform Heating

References

[1] R. Kumar, M. A. Kalam, Laminar thermal convection between vertical coaxial isothermal cylinders, Int. J. Heat Mass Transf., 34(2), (1991) 513 -524.

DOI: 10.1016/0017-9310(91)90270-o

[2] M. Sankar, Y. Do, S. Ryu, B. Jang, Cooling of heat sources by natural convection heat transfer in a vertical annulus, Numerical Heat Transf. Part A Appl., 68(8), 2015, 847 -869.

DOI: 10.1080/10407782.2015.1023097

[3] M. Sankar, B. Kim, J. M. Lopez, Y. Do, Thermosolutal convection from a discrete heat and solute source in a vertical porous annulus, Int. J. Heat Mass Transf., 55(15/16), (2012) 4116 -4128.

DOI: 10.1016/j.ijheatmasstransfer.2012.03.053

[4] M. Sankar, Y. Park, J. M. Lopez, Y. Do, Numerical study of natural convection in a vertical porous annulus with discrete heating, Int. J. Heat Mass Transf., 54(7/8), (2011) 1493 -1505.

DOI: 10.1016/j.ijheatmasstransfer.2010.11.043

[5] M. Sathiyamoorthy, T. Basak, S. Roy, I. Pop, Steady natural convection flows in a square cavity with linearly heated side wall(s), Int. J. Heat Mass Transfer. 50, (2007) 766 -775.

DOI: 10.1016/j.ijheatmasstransfer.2006.06.019

[6] M. Sathiyamoorthy, A. Chamkha, Effect of magnetic field on natural convection flow in a liquid gallium filled square cavity for linearly heated side wall(s). Int. J. Thermal Sciences, 49, (2010) 1856-1865.

DOI: 10.1016/j.ijthermalsci.2010.04.014

[7] K. Al-Salem, H. F. Oztop, I. Pop, Y. Varol, Effects of moving lid direction on MHD mixed convection in a linearly heated cavity, Int. J. Heat Mass Transfer, 55, (2012) 1103 -1112.

DOI: 10.1016/j.ijheatmasstransfer.2011.09.062

[8] E. Natarajan, S. Roy, T. Basak, Effect of various thermal boundary conditions on natural convection in a trapezoidal cavity with linearly heated side wall(s), Numerical Heat Transfer, Part B: Fundamentals, 52(6), (2007) 551-568.

DOI: 10.1080/10407790701563623

[9] T. Basak, S. Roy, Ch. Thirumalesha, Finite element analysis of natural convection in a triangular enclosure: Effects of various thermal boundary conditions, Chemical Engineering Science, 62, (2007) 623-2640.

DOI: 10.1016/j.ces.2007.01.053

[10] S. Das, R.N. Jana, O.D. Makinde, Radiation effect on a fully developed mixed convection in a vertical channel filled with nanofluids. Journal of Nanofluids 4(3), (2015) 362-368.

DOI: 10.1166/jon.2015.1155

[11] G. Singh, O. D. Makinde: Axisymmetric slip flow on a vertical cylinder with heat transfer. Sains Malaysiana 43(3), (2014) 483–489.

[12] O. D. Makinde, Similarity solution for natural convection from a moving vertical plate with internal heat generation and a convective boundary condition. Thermal Science, 15(1), (2011) S137-S143.

DOI: 10.2298/tsci11s1137m
