Distortion in Induction-Hardened Cylindrical Part

Abstract:

This article concerns distortion of a workpiece after induction-hardening under various conditions. It focuses particularly on the effects of quenching water temperature, PAG polymer concentration and the rotation speed of the workpiece during induction hardening. Electrical as well as non-electrical quantities which affect the process were monitored. They included the current passing through the inductor, the power frequency, quenching water temperature, the flow rate of the quenchant through the spray-quench device, the speed of rotation of the workpiece and some others. The workpiece was a cylinder 70 mm in length which contained a drilled off-axis through hole. Prior to hardening, dimensions of the workpiece and the hole were measured on three planes set in different distances from the bottom face. The measurement was repeated after induction hardening and the findings are reported in this article. Post-process hardness was measured on the cylindrical surface of the workpiece. Hardening depths obtained with different quenchants were measured.

• Periodical: Defect and Diffusion Forum (Volume 395)
• Pages: 30-44
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.395.30
• Online since: August 2019
• Authors: Jiří Hájek*, David Rot, Jakub Jiřinec
• Keywords: C35E Steel, Deformation, Distortion, Hardness after Induction Hardening Process, Induction Hardening Process

References

[1] Jirinec, S., Rot D. Data Acquisition System for Cold Crucible, Online, Transactions On Electrical Engineering 2017, 6 (1) 28-31, http://www.transoneleng.org/.

[2] Rot, D., Jirinec, J., Jirinec S., Kožený J., Advanced Measurements for Analysis and Data Acquisition from the Cold Crucible, In 2016 17Th International Scientific Conference On Electric Power Engineering (Epe), pp.1-4, Prague: IEEE,.

DOI: 10.1109/EPE.2016.7521780

[3] Hájek, J., Kříž, A., Jirka T. Distortion after Case Hardening of steels. Manufacturing Technology, 2016, vol. 16, no. 4, pp.697-702. ISSN: 1213-2489.

DOI: 10.21062/ujep/x.2016/a/1213-2489/mt/16/4/697

[4] Nováková, M., Chocholatý, O., Kříž, A. Vliv deformace na korozní vlastnosti materiálu. Koroze a ochrana materiálu, 2017, vol. 61, no. 3, pp.86-90. ISSN: 0452-599X.

DOI: 10.2478/v10227-011-0022-7

[5] Beneš, P., Kotrba, M., Kříž A. Alternative uses of eddy current inspection in materials engineering. Manufacturing Technology, 2016, vol. 16, no. 6, pp.1240-1243. ISSN: 1213-2489.

DOI: 10.21062/ujep/x.2016/a/1213-2489/mt/16/6/1240

[6] Rudnev, V. Induction Heating and Heat Treatment ASM Handbook, Volume 4C. ASM International, 2014. ISBN 978-1627080125.

[7] Rudnev, V. Handbook of Induction Heating. CRC Press; 2 edition, 2017. ISBN 978-1466553958.
