The Effect of Nitrogen on the Capacitive Properties of N-Doped rGO/CuCr₂O₄ Composites as Materials for Supercapacitors

Abstract:

A hybrid supercapacitor is an energy storage device that combines the properties of EDLCs and pseudocapacitors. In this research, the goal was to analyze the effect of hydrothermal temperature on the structure, morphology, and capacitive properties of the N-Doped reduced graphene oxide/Copper Chromite (N-Doped rGO/CuCr₂O₄) composite, which was being investigated as a potential material for hybrid supercapacitor electrodes. The method used was hydrothermal, with temperature variations of 120°C, 140°C, and 160°C. The structure and morphology of the composites were analyzed using Scanning Electron Microscope (SEM) and Energy Dispersive X-Ray Analysis (EDX), X-Ray Diffractometer (XRD), and Fourier Transform Infrared Spectrometer (FTIR). Meanwhile, the capacitance and conductivity values of N-doped rGO/CuCr₂O₄ were measured using Cyclic Voltammetry (CV) and Electrochemical Impedance Spectroscopy (EIS) tests. The results of the XRD tests showed that an increase in temperature led to a greater d_spacing value, indicating the presence of more substituted nitrogen atoms. This was supported by the results from EDX, which showed that the sample with a hydrothermal temperature of 160°C had the largest percentage of nitrogen. Nitrogen is important in increasing the conductivity of the material. The FTIR results revealed a covalent bond between Carbon (C) and Nitrogen (N). Meanwhile, the results of the CV test, performed at a scan rate of 5 mV/s and a potential window of 0-0.8 V, showed that the specific capacitance values were 99.5, 196.16, and 221.59 Fg^-1 for the samples with hydrothermal temperatures of 120°C, 140°C, and 160°C, respectively. The EIS test measured the conductivity values of the samples, which were 0.123, 0.518, and 0.549 S/m for the samples with hydrothermal temperatures of 120°C, 140°C, and 160°C, respectively. Thus, the specific capacitance values were influenced by the electrical conductivity of the materials and the nitrogen doping content in the electrode composite material.

• Periodical: Engineering Chemistry (Volume 5)
• Pages: 49-56
• DOI: https://doi.org/10.4028/p-i1dZ9Z
• Online since: January 2024
• Authors: Diah Susanti*, Adzon Nugraha Rizky Pratama, Haniffudin Nurdiansah
• Keywords: Hybrid Supercapacitor, Hydrothermal, N-Doped rGO/CuCr₂O₄ Composite, Specific Capacitance

References

[1] H. Lund, Renewable energy strategies for sustainable development, Energy. 32:6 (2007) 912–919.

DOI: 10.1016/j.energy.2006.10.017

[2] V. D. Nithya, A review on holey graphene electrode for supercapacitor, J. Energy Storage. 44:PB (2021) 103380.

DOI: 10.1016/j.est.2021.103380

[3] A. González, E. Goikolea, J. A. Barrena, and R. Mysyk, Review on supercapacitors: Technologies and Materials, Renew. Sustain. Energy Rev. 58(2016) 1189–1206.

DOI: 10.1016/j.rser.2015.12.249

[4] G. A. Ferrero, A. B. Fuertes, and M. Sevilla, N-doped porous carbon capsules with tunable porosity for high-performance supercapacitors, J. Mater. Chem. A. 3:6 (2015) 2914–2923.

DOI: 10.1039/c4ta06022a

[5] A. U. Sokolnikov, Graphene for Defense and Security. RC Press, Boca Raton-Florida, ISBN: 1351646680, 9781351646680, 2017.

[6] C. Lee, X. Wei, J. W. Kysar, and J. Hone, Measurement of the elastic properties and intrinsic strength of monolayer graphene, Sci. 321:5887 (2008) 385–388.

DOI: 10.1126/science.1157996

[7] Y. Zhu and S. Murali., Graphene and graphene oxide: Synthesis, properties, and applications, Adv. Mater. 22:35 (2010) 3906–3924.

DOI: 10.1002/adma.201001068

[8] L. Ma, Z. Wang, S. Tian, X. Liu, Z. Li, J. Huang, D. Xiyu, and Y. Huang, The αFe2O3/graphite anode composites with enhanced electrochemical performance for lithium-ion batteries, Nanotech. 31:43 (2020) 435404

DOI: 10.1088/1361-6528/aba3a0

[9] J. Safaei-Ghomi, Z. Akbarzadeh, and B. Khojastehbakht-Koopaei, C–N cross-coupling reaction catalysed by reusable CuCr2O4 nanoparticles under ligand-free conditions: a highly efficient synthesis of triarylamines, RSC Adv. 3:37 (2015) 28879-28884

DOI: 10.1039/C5RA01915J

[10] F. Fitrony, R. Fauzi, L. Qadariyah, and M. Mahfud, Pembuatan Kristal Tembaga Sulfat Pentahidrat (CuSO4.5H2O) dari Tembaga Bekas Kumparan, Jurnal Teknik ITS. 2:1 (2013) F121-F125

[11] M. H. Habibi and F. Fakhri, Fabrication and Characterization of CuCr2O4 Nanocomposite by XRD, FESEM, FTIR, and DRS, Synth. React. Inorganic, Met. Nano-Metal Chem. 46:6 (2016) 847–851.

DOI: 10.1080/15533174.2014.989591

[12] S. Sarkar, R. Akshaya, and S. Ghosh, Electrochimica Acta Nitrogen doped graphene/CuCr2O4 nanocomposites for supercapacitors application : Effect of nitrogen doping on coulombic efficiency, Electrochim. Acta. 332 (2020) 135368. https://doi.org/10.1016/j.electacta. 2019.135368

DOI: 10.1016/j.electacta.2019.135368

[13] S. Angelika, D. Susanti, and Nurdiansah, H, Analisis Pengaruh Komposisi Material Komposit terhadap Sifat Kapasitif Superkapasitor Berbahan N-doped rGO/CuCr2O4, Undergraduate Thesis, Department of Materials and Metallurgical Engineering Department, Institut Teknologi Sepuluh Nopember (ITS), Surabaya-Indonesia, 2022.

DOI: 10.12962/j23373539.v6i1.21409
