A Study on the Monitoring of Nano Scale EHL Film Formation with Ultra Low Aspect Ratio

Abstract:

The measurement of ultra low aspect ratio fluid film thickness is very crucial technique both for the verification of lubrication media characteristics and for the clearance design in many precision components such as MEMS, precision bearings and other slideways. Many technologies are applied to the measurement of ultra low aspect ratio fluid film thickness (i.e. elastohydrodynamic lubrication film thickness). In particular, in-situ optical interferometric method has many advantages in making the actual contact behaviors realized with the experimental apparatus. This measurement method also does the monitoring of the surface defects and fractures happening during the contact behavior, which are delicately influenced by the surface conditions such as load, velocity, lubricant media as well as surface roughness. Careful selection of incident lights greatly enhances the fringe resolutions up to ~1.0 nanometer scale with digital image processing technology. In this work, it is found that coaxial aligning trichromatic incident light filtering system developed by the author can provide much finer resolution of ultra low aspect ratio fluid film thickness than monochromatic or dichromatic incident lights, because it has much more spectrums of color components to be discriminated according the variations of film thickness. For the measured interferometric images of ultra low aspect ratio fluid film thickness it is shown how the film thickness is finely digitalized and measured in nanometer scale with digital image processing technology and space layer method. The developed measurement system can make it possible to visualize the contact deformations and possible fractures of contacting surface under the repeated loading condition.

• Periodical: Key Engineering Materials (Volumes 297-300)
• Pages: 257-262
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.297-300.257
• Online since: November 2005
• Authors: Si Youl Jang, Hyun Sang Kong
• Keywords: Aspect Ratio, Coaxial Alignment, Elastohydrodynamic Lubrication EHL, Image Processing Method, Nano Resolution, Nano Scale Film Thickness, Trichromatic Incident Light Filtering System

References

[1] B. Bhushan: Micro/Nano Tribology, CRC Press LLC (ISBN 0-8493-8402-8, 1999).

[2] B. Bhushan: Fundamentals of Tribology and Bridging the Gap between the Macro- and Micro/ Nanoscales (Kluwer Academic Publishers, ISBN 0-723-6863-3, 2001).

DOI: 10.1007/978-94-010-0736-8

[3] M. Kaneta: For the Establishment of a New EHL Theory, Lubrication at the Frontier, Elsevier Science B.V. (1999), pp.25-36.

[4] M. Born and E. Wolf: Principles of Optics (Pergamon Press, Ltd., ISBN 0-521-63921-2, Oxford 1997).

[5] S. Jang and H. Kong: Friction force Measurement of Elastohydrodynamic Lubrication with Viscosity Index Improvers, KSTLE Spring Conference (2001), pp.267-271.

[5] H. Levkowits: Color Theory and Modeling for Computer Graphics, Visualization, and Multimedia Applications (Kluwer Academic Publishers, Boston 1997).

[6] R.P. Glovnea and H. Spikes: Behaviour of EHD films during reversal of entrainment in cyclically accelerated/decelerated motion, 56 th STLE (2001).

DOI: 10.1080/10402000208982537

[7] I. Krupka, M. Hartl, R. Poliscuk and M. Liska: Experimental Study of Central and Minimum Elastohydrodynamic Film Thickness by Colorimetric Interferometry Technique, Tribology Transactions 43 (2000), pp.611-618.

DOI: 10.1080/10402000008982385
