Vibration Fatigue Reliability of Lead and Lead-Free Solder Joint by FORM/SORM

Abstract:

It is well-known that the vibration significantly affect the life of solder joint. In this paper, the effects of the vibration on the failure probability of the solder joint are studied by using the failure probability models such as the First Order Reliability Method (FORM) and the Second Order Reliability Method (SORM). The accuracies of the results are estimated by a help of the Monte Carlo Simulation (MCS). The reliability of the lead and the lead-free solder joint was also evaluated. The reliability of lead-free solder joint is found to be higher than that of lead solder joint.

• Periodical: Key Engineering Materials (Volumes 345-346)
• Pages: 1393-1396
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.345-346.1393
• Online since: August 2007
• Authors: Ouk Sub Lee, Man Jae Hur, Yeon Chang Park, Dong Hyeok Kim
• Keywords: Failure Probability, Form, MCS, Reliability, Solder Joint, SORM, Vibration

References

[1] C. Basaran, R. Dhandaroy: Mechanics of Pb40/Sn60 neareutectic solder alloy subjected to vibration., Appl Math Model, Vol 22 (1998), pp.601-627.

DOI: 10.1016/s0307-904x(98)10059-8

[2] S. Mahadevan and A. Haldar: Reliability Assessment Using Stochastic Finite Element Analysis (John Wiley & Son, 2000).

[3] O.S. Lee, S.S. Choi and D.H. Kim: Solid State Phenomena, Vol. 110 (2006), pp.221-230.

[4] O.S. Lee and D.H. Kim: Key Engineering Materials, Vol. 326-328 (2006), pp.597-600.

[5] O.S. Lee, M.J. Hur, J.S. Hawong, N.H. Myoung and D.H. Kim: Key Engineering Materials, Vol. 326-328 (2006), pp.621-624.

DOI: 10.4028/www.scientific.net/kem.326-328.621

[6] O.S. Lee and D.H. Kim: KSME Int. J., Vol. 19 (2005), pp.1280-1289.

[7] Y.B. Kim, H. Noguchi, M. Amagai: Microelectronics Reliability Vol. 46 (2006), pp.459-466.
