The Effect of a Free Drop Impact on the Bolted Joint of the Radioactive Transport Package

Abstract:

In this study the effect of a free drop impact on the bolted joint of the transport package of radioactive material was studied under various directions. A drop test of a type A or a type IP transport package of radioactive material should be conducted under normal transport conditions. After a drop test the radioactive content of the transport package should not be loss or dispersal. A bolt tension during a drop impact under various directions was measured using a force sensor. And the torque to loosen a bolt was measured after the tests. A bolt tension measured by the tests was compared with the result of a finite element analysis. The effect of the drop direction was examined. The vertical drop directions shows larger bolt tension than horizontal drop. For the torque to loosen a bolt, a horizontal drop condition shows larger value than a vertical drop direction.

• Periodical: Key Engineering Materials (Volumes 345-346)
• Pages: 1421-1424
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.345-346.1421
• Online since: August 2007
• Authors: Dong Hak Kim, Ki Seong Seo, Ju Cahn Lee
• Keywords: Bolt, Finite Element Analysis Method, Free Drop Test, Radioactive Transport Package

References

[1] IAEA Safety standard Series No. TS-R-1, (2005). Regulations for Packaging and Transportation of Radioactive Material.

[2] U.S. Code of Federal Regulations, Title 10, Part 71, (2004). Packaging and Transportation of Radioactive Material.

[3] Quercetti T. Wieser G. Völzke, H. and Zeisler P. (1994) Analytical, numerical and experimental investigations on the impact behavior of selected structures. Nuclear Engineering and Design, 150: 287-293.

DOI: 10.1016/0029-5493(94)90146-5
