Reliable Detection of Periodic Micro Structures on Open Surfaces

Abstract:

The reliable determination of periodic micro structures on open surfaces as they exist on involute tooth flanks gain of increasing importance. They allow conclusions from the waviness of the gear surface to the wear and running noise in gears. With the aim of determining traceable wave structures, a method has been developed at the Physikalisch-Technische Bundesanstalt (PTB) in Braunschweig by which it is possible to model, realise and, especially, reliably evaluate wave-shaped structures on the flank surfaces of involute cylindrical gears.

• Periodical: Key Engineering Materials (Volumes 381-382)
• Pages: 15-18
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.381-382.15
• Online since: June 2008
• Authors: Frank Härtig, Michael Paul Krystek, S. Klein
• Keywords: Calibration, Dimensional Measurement, Micro Metrology, Surface Metrology, Traceability, Uncertainty

References

[1] O. Richter: Master theses Fachhochschule Lübeck, (2005).

[2] F. Härtig, O. Jusko, O. Richter, F. Wäldele: Patentanmeldung 10 2005 018 582. 7, (2005).

[3] K. Zirpke: Zahnräder, VEB Fachbuchverlag Leipzig, 13. Auflage, 1989, ISBN 3-343-00087-6.

[4] DIN 3960: Definitions, parameters and equations for involute cylindrical gears and gear pairs, Beuth Verlag (1987).

[5] DIN ISO / TS 12780-2: Geometrische Produktspezifikation (GPS) - Geradheit - Teil 2: Spezifikationsoperatoren.

DOI: 10.31030/1736141

[6] W. Lotze: Eigenverlag, 3. Auflage, 2006, ISBN 3-00-015962-2.

[7] M. Krystek: PTB-Mitteilungen 116 (2006) Heft 3.

[8] J. W. Cooley, J. W. Tukey: An Algorithm for the Machine Calculation of Complex Fourier Series, Mathematics of Computation 19, 297-301, (1965).

DOI: 10.1090/s0025-5718-1965-0178586-1

[9] E. O. Brigham: The Fast Fourier Transform, Englewood Cliffs NJ, Prentice Hall, 1974 a) b).
