Simulation of Dynamic Performance for Hydro-Hybrid Spindle-Bearing System of Superhigh Speed Grinder

Abstract:

Spindle-bearing system plays a crucial role in superhigh speed grinding, which directly affects machining precision, but it is complex and difficult to get the dynamic performance in experiment. This leads to study how to accurately simulate dynamic performance of spindle-bearing system. So a method which springs and damping units imitate bearing support is proposed in this paper. The proposed method can predict the regular pattern which bearing stiffness and damping ratio affect natural frequency and harmonic response. The research demonstrates that the method predicts well the dynamic performance of the spindle-bearing system and it is close to actual condition, therefore, it can be a reference for dynamic optimization design of spindle-bearing system in superhigh speed grinding.

• Periodical: Key Engineering Materials (Volumes 389-390)
• Pages: 252-257
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.389-390.252
• Online since: September 2008
• Authors: Wan Shan Wang, L.D. Zhu, Tian Biao Yu, Jia Shun Shi, He Li
• Keywords: Dynamic Performance, Finite Element Model (FEM), Simulation, Spindle-Bearing System, Super-High Speed Grinding

References

[1] Hwang T W, EVANS C J, Whitenton E P, et al. High speed grinding of silicon nitride with electroplated diamond wheels, part 1: wear and wheel life. Journal of manufacturing Science and Engineering, Vol. 122 (2), (2000). pp.32-41.

DOI: 10.1115/1.538908

[2] Lanvine A S, Malkin S, Jen T C. Thermal aspects of grinding with CBN wheels. Annals of CIRP, Vol. 38 (1) (1989), pp.557-560.

DOI: 10.1016/s0007-8506(07)62768-1

[3] Klocke F, Baus A, Beck T. Coolant induced forces in CBN high speed grinding with shoe nozzle. Annals of the CIRP, Vol. 49 (1), (2000), pp.241-244.

DOI: 10.1016/s0007-8506(07)62937-0

[4] W. R Wang, C. N Chang, Dynamic analysis and design of a machine tool spindle-bearing system, Transactions of the ASME, Journal of Vibration and Acoustics, Vol. 116 (3), (1994), pp.280-285.

DOI: 10.1115/1.2930426

[5] V Gagnol., et al., Stability-Based Spindle Design Optimization, Transactions of the ASME, Journal of Manufacturing Science and Engineering, Vol. 129 (2), (2007), pp.407-415.

[6] Y.Z. Cao, Y Altintas, A general method for the modeling of spindle-bearing systems, Transactions of the ASME. Journal of Mechanical Design, Vol. 126(8), (2004), pp.1089-104.

DOI: 10.1115/1.1802311

[7] I.A. Zverev, U.E. In, K. H Yong, An elastic deformation model of high-speed spindle units, International Journal of Precision Engineering and Manufacturing, vol. 7(3), (2006), pp.39-46.
