Effects of Grain Size and Concentration of Grinding Wheel in Ultrasonically Assisted Grinding

Abstract:

This study aims to develop an ultrasonically assisted grinding technology for precision internal grinding of a small hole measuring several millimeters in diameter, such as those formed in a fuel injector for an automotive engine. In a previous work, an experimental apparatus mainly composed of an ultrasonic vibration spindle was designed and constructed, and grinding experiments were carried out. The purpose of this paper is to examine the effect of ultrasonic vibration on grinding force and surface roughness when the grain size and concentration of small cBN grinding wheel are changed. The experimental results indicate that applying ultrasonic vibration to the wheel decreases the normal and tangential grinding forces by more than 50% and 78%, respectively, and improves the surface roughness by as much as 10% when the wheel grain size and concentration are changed. In addition, over the range of grinding conditions employed in this paper, the grain size as small as 5μm can be used in ultrasonically assisted grinding.

• Periodical: Key Engineering Materials (Volumes 389-390)
• Pages: 283-288
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.389-390.283
• Online since: September 2008
• Authors: Mitsuyoshi Nomura, Yong Bo Wu, Tsunemoto Kuriyagawa, Takahiro Kawashima, Takayuki Shibata
• Keywords: Grinding Force, Internal Grinding, Surface Roughness (SR), Ultrasonic Vibration

References

[1] P. Logge: Ultrasonic, Jul., (1966) p.157.

[2] A.I. Markov, et al.: Industrial Diamond Review.

[3] (1972), p.97.

[3] K. Unno, et al.: Journal of JSPE, (in Japanese), Vol. 52, No. 1 (1986), p.107.

[4] J. Kumabe: Journal of JSPE, (in Japanese), Vol. 27, No. 6 (1961), p.369.

[5] K. Suzuki, et al.: Kikai to Kougu (Machines and Tools), (in Japanese), No. 6 (2000), p.89.

[6] Y. Tanaka, et al.: Journal of JSPE, (in Japanese), Vol. 29, No. 3 (1963), p.232.

[7] Y. Tanaka, et al.: Journal of JSPE, (in Japanese), Vol. 30, No. 3 (1964), p.253.

[8] Y. Tanaka, et al.: Journal of JSPE, (in Japanese), Vol. 31, No. 5 (1965), p.375.

[9] Y. Wu, et al.: Journal of JSAT, (in Japanese), Vol. 47, No. 10 (2003), p.550.

[10] Y. B. Wu, et al.: Materials Science Forum, Vols. 471-472 (2004), pp.101-106.

[11] G. Nishimura and Y. Yokoyama, Journal of JSPE, (in Japanese), Vol. 31, No. 5 (1965), p.390.

[12] K. Suzuki, T. Uematsu and T. Makizaki, Kikai to Kougu (Machines and Tolls), (in Japanese), No. 7 (2000).
