Research on Ultrasonic Vibration Combined with Grinding Machining and its Application in Processing Brittle Hard Materials

Abstract:

A system of ultrasonic combined with grinding has been designed, and one novel connective method of straight screw combined with taper surface has been applied in spindle, so compact size and high revolving accuracy can be achieved. Modal analysis of ultrasonic vibration system has been implemented by FEM (Finite Element Method), and its optimal dimension has been calculated to find out optimal vibration estate. Full-bridge converter has been applied in driving circuit of ultrasonic vibrator, and auto-frequency tracking has been designed in order that ultrasonic vibration works on resonant or quasi-resonant frequency. Finally, machining experiments have been fulfilled about ultrasonic combined with grinding, and its machining effect has been distinctly improved comparing ordinary grinding machining.

• Periodical: Key Engineering Materials (Volumes 447-448)
• Pages: 223-227
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.447-448.223
• Online since: September 2010
• Authors: Yong Jun Zhang, Yong Jun Tang, Xiao Kang Liu
• Keywords: Brittle Hard Material, Grinding Machining, High Removal Rate, Ultrasonic Vibration

References

[1] Rajurkar K P, Wang Z Y, Kuppattan A. Micro removal of ceramic material (Al2O3) in the precision machining. Precision Engineering, 1999(23): 73-78.

DOI: 10.1016/s0141-6359(98)00026-9

[2] Guzzo P L, Raslan A A, De mello J D B. Ultrasonic abrasion of quartz crystals. Wear 2003, 255: 67-77.

DOI: 10.1016/s0043-1648(03)00094-2

[3] Wang H S. Analysis of the Effect of Process Parameters on Material Removal Rate in Ultrasonic Machining. Bethlehem: Legigh University, (1998).

[4] Churi, N.J., Pei, Z.J.; Shorter, D.C.; Treadwell, C. Rotary ultrasonic machining of silicon carbide: designed experiments. International Journal of Manufacturing Technology and Management, 2007, v. 12, n1-3: 284-98.

DOI: 10.1504/ijmtm.2007.014154

[5] Weimin Zeng, Xipeng Xu, Zhijian Pei. Rotary ultrasonic machining of advanced ceramics. Materials Science Forum, 2007, v. 532-533: 361-4.

DOI: 10.4028/www.scientific.net/msf.532-533.361

[6] Hocheng H, Kuo K L. Fundamental study of ultrasonic polishing of mold steel. International Journal of Machine Tools & Manufacture, 2002, 42: 7-13.

DOI: 10.1016/s0890-6955(01)00099-2

[7] Rajurkar K P, Wang Z Y, Kuppattan A. Micro removal of ceramic material (Al2O3) in the precision machining[J]. Precision Engineering, v23, 1999, pp.73-78.

DOI: 10.1016/s0141-6359(98)00026-9

[8] Lin Shuyu. Load characteristics of high power sandwich piezoelectric ultrasonic transducers [J]. Ultrasonics, v43, 2005, pp.365-373.

DOI: 10.1016/j.ultras.2004.07.008
