Fabrication of Ultraprecision Millimeter-Thick Elliptical Neutron Focusing Mirror Substrate by Local Wet Etching

Abstract:

Numerically controlled local wet etching (NC-LWE) is a novel technique to fabricate the ultraprecision optical components and/or finishing the functional materials. In this technique, a figuring is performed by controlling the dwelling time of the combination nozzle, which consists of a supply and a suction part of an etchant, on the workpiece. In this paper, we proposed fabrication process of millimeter-thick elliptical neutron focusing mirror substrate by applying NC-LWE figuring involving CeO2 slurry polishing. We fabricated a millimeter-thick elliptical neutron focusing mirror substrate with a figure error of less than 0.2 μm and obtained a surface roughness of less than 0.15 nm rms.

• Periodical: Key Engineering Materials (Volumes 447-448)
• Pages: 208-212
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.447-448.208
• Online since: September 2010
• Authors: Fumiya Yamaga, Mikinori Nagano, Nobuyuki Zettsu, Dai Yamazaki, Ryuji Maruyama, Kazuhiko Soyama, Kazuya Yamamura
• Keywords: Elliptical Mirror, Focusing, Ion Beam Sputtering, Local Wet Etching, Neutron Supermirror

References

[1] K. Yamamura: Ann. of the CIRP Vol. 56/1 (2007), p.541.

[2] R. Maruyama, D. Yamazaki, T. Ebisawa, M. Hino, K. Soyama: Physica B Vol. 385-386 (2006), p.1256.

DOI: 10.1016/j.physb.2006.06.024

[3] R. Maruyama, D. Yamazaki, T. Ebisawa, M. Hino, K. Soyama: Thin Solid Films Vol. 515 (2007), p.5704.

DOI: 10.1016/j.tsf.2006.12.022

[4] R. Maruyama, D. Yamazaki, T. Ebisawa, K. Soyama: Nucl. Instr. and Meth. Vol. A 600 (2009), p.68.

[5] K. Yamamura, M. Nagano, H. Takai, N. Zettsu, D. Yamazaki, R. Maruyama, K. Soyama S. Shimada: Opt. Express Vol. 17 (2009), p.6414.

DOI: 10.1364/oe.17.006414
