A New Air-Conditioning Pipeline Cleaning Robot System

Abstract:

Presently most of the air-conditioning pipeline cleaning robots in the market do not have the self-adaptive capacity to variable diameter pipelines, and clean the circular pipeline incompletely, have the whipping problems in the working process. For this case, this paper developed a new type of pipe robot; the robot adopts the umbrella-like open-and-close mechanism, scissors lifting mechanism and tail location and navigation device. It can align the center of the circular pipes with different diameters automatically, and sweep 360° one-time, improve the efficiency and stability of the robot greatly.

• Periodical: Key Engineering Materials (Volume 464)
• Pages: 313-317
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.464.313
• Online since: January 2011
• Authors: Zhi Xiang Li, Heng Wu Li, Zhi Hui Li
• Keywords: Auto Alignment Center, Location, Navigation, Pipeline Cleaning, Pipeline Robot

References

[1] Wang Ya: Air-conditioning duct cleaning robot appeared, New era of science and technology [J], 2005. 09.

[2] Li Jun, Yuting Wu, Chongfang Ma and Zhiwei Tang: Cleaning world, Vol. 21 (2005), No. 7.

[3] Ma Hong, Suping Bai and Renfeng Yan: Chinese journal of scientific instrument, 2005, 26 (8): pp.286-287.

[4] Limin Mao: Cleaning world, 2004, 20 (5): pp.58-60.

[5] Xu Xiang: Pipe robot research and engineering applications. [master's thesis], Shanghai: Donghua University. (2006).

[6] Wangan Min, Qizhong Wang and Zhaomin He: Mechanical and electronic engineering technology, Vol. 35, 2006. 10.

[7] Y. Kawaguchi: Internal pipe inspection robot，IEEE International Conferenee and Automation, 1999, vol. l: pp.857-862.
