The Application of Modal Analysis in Hole-Defect in Lumber

Abstract:

Larch lumbers were tested by using modal analysis technology and Frequency response functions (FRF) were derived. Modal parameters, including first 4 intrinsic frequency and first 3 modal shape, were distinguished by single modal method. Research shows that the intrinsic frequency of hole-defect lumbers is little lower than standard lumbers’ and the change rate of frequency is becoming larger gradually with the diameter of hole-defect. However, it can not judge the position of the hole-defect by the change rate of frequency. The modal shape of the node near the hole-defect always jumps abruptly, so it can estimate the particular position of hole-defect in the lumber. The variation of modal shape is becoming larger gradually with the diameter of hole-defect. It can make qualitative and quantitative estimate to the hole-defect in the lumber by considering intrinsic frequency and modal shape together.

• Periodical: Key Engineering Materials (Volumes 467-469)
• Pages: 1776-1780
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.467-469.1776
• Online since: February 2011
• Authors: Shi Quan Song, Hua Dong Xu, Li Hai Wang
• Keywords: Hole-Defect, Lumber, Modal Analysis, Testing

References

[1] Wang Lihai, Yang Xuechun, Xu Kaihong. Current Situaton of Research on the Non-Destructive Testing Technique for Wood Defects[J]. Forestry Science and Technology, 2002, 27(3): 35-38.

[2] Xiaoyang Yang，Takuro Amano，Yutaka Ishimaru. Application of modal analysis by transfer function to nondestructive testing of wood I： determination of localized defects in wood by the shape of the flexural vibration wave[J]. Journal of Wood Science. 2002, 48（4）: 283-288.

DOI: 10.1007/bf00831348

[3] Xiaoyang Yang，Takuro Amano，Yutaka Ishimaru. Application of modal analysis by transfer function to nondestructive testing of wood II： modulus of elasticity evaluation of sections of differing quality in a wooden beam by the curvature of the flexural vibration wave[J]. Journal of Wood Science. 2003, 49（5）: 140-144.

DOI: 10.1007/s100860300022

[4] Li Debao, Lu Qiuhai. EXPERIMENT MODAL ANALYSIS AND ITS APPLICATION [M]. Beijing Science Press, 2001: 92-110.

[5] Chuanshuang Hu，Muhammad T. Afzal. A statistical algorithm for comparing mode shapes of vibration testing before and after damage in timbers[J]. Journal of Wood Science. 2006, 52（4）: 348- 352.

DOI: 10.1007/s10086-005-0769-9
