Dynamic Disturbance Simulation of Modal Control and Control Model of Torsional Vibration of the Rolling Mill

Abstract:

For suppressing torsional vibration on main driving system of the rolling mill, the paper studied modal control and control model of torsional vibration. Dynamic disturbance of the rolling mill main driving system were induced by small perturbation from torque fluctuation. Modal control analysis were investigated on include amplitude and phase response on reference change or load change, bode diagrams, and time domain simulations. Torque fluctuation reflects non-steady cyclical or quasi-cyclical characteristics on the torsional vibration system. Control model had been reconstructed from inversion of dynamic topology theory. The result of simulation showed that the established control model for suppressing torsional vibration was effectiveness. Feedback control experiment of nipping and throwing steel on the rolling mill’s main driving system using reaction control tactic was proved it could be easy input and output for controling to suppressing vibration.

• Periodical: Key Engineering Materials (Volumes 467-469)
• Pages: 509-514
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.467-469.509
• Online since: February 2011
• Authors: Wu Zhao, Dan Huang
• Keywords: Control Model, Modal Control, Rolling Mill’s Main Driving System, Time Domain Simulation, Torsional Vibration

References

[1] Belli P, Bittanti S, De Marco. On the origin of torsional vibrations in hot rolling mills and a possible remedy. Journal of Dynamic Systems, Measurement and Control, Transactions of the ASME, 2004, 126(4): 811-823.

DOI: 10.1115/1.1850531

[2] Neng-Sheng Pai1, Yi-Pin Kuo. Speed Control for a Two-Mass Drive System Using Integrated Fuzzy Estimator and Hybrid Fuzzy PD/PI Controller, 2007 International Symposium on Nonlinear Dynamics (2007 ISND): 1-7.

DOI: 10.1088/1742-6596/96/1/012094

[3] Zhao Wu, Liu Bin. Torsional Vibration Calculation of Rolling Mill Based On Topology Network. Chinese Journal of Mechanical Engineering, 2006, 42(7): 49-61.

DOI: 10.3901/jme.2006.07.051

[4] Zhao Wu. Study on torsional vibration of large rotation shaft. 2009 8th international conference on reliability, maintainability and safety, 844-848.

DOI: 10.1109/icrms.2009.5269953

[5] Zhao Wu. Investigations on torsional vibration in the precision heavy machinery. 2009 International Asia Conference on Informatics in Control, Automation, and Robotics, 459-463.

DOI: 10.1109/car.2009.91

[6] Liu Bin, Yang Haima, Liu Jin. Rolling mill coupling spindle dynamic torque survey and reaction control model research. Instrument measuring appliance journal, 2005, vol 26 (5): 537-541.
