Electrode Tool Wear at Electrical Discharge Machining

Abstract:

As consequence of the development of electrical discharge machining process, the electrode is affected by wear; knowing the evolution of the electrode wear, a better estimation of its service life is possible. It is expected that the electrode wear depends on the energy of the electrical discharges and the mass of the electrode. It is known also that the nature of the workpiece material exerts influence on the evolution of the electrode wearing process. In the paper, some theoretical considerations are used to highlight the above mentioned aspects. A set of experimental tests was designed and developed in order to highlight the influence exerted by the nature of the workpiece material and by the size of the cross section of the electrode, respectively, on the electrode wear. Empirical mathematical models corresponding to the evolution of the electrode wear were established.

• Periodical: Key Engineering Materials (Volumes 504-506)
• Pages: 1189-1194
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.504-506.1189
• Online since: February 2012
• Authors: Laurenţiu Slătineanu, Hans Peter Schulze, Oana Dodun, Margareta Coteaţă, Lorelei Gherman, Irina Grigoraş (Beşliu)
• Keywords: Electrical Discharge Machining (EDM), Electrode Wear, Empirical Mathematical Model, Workpiece Material

References

[1] H. Huang, J. Bai, Z. Lu, Y.F. Guo, Electrode wear prediction in milling electrical discharge machining based on radial basis function neural network, J. Shanghai Jiaotong Univ. (Sci.), 2009, 14(6) (2009) 736-741

DOI: 10.1007/s12204-009-0736-5

[2] H.-P. Schulze, G. Wollenberg, T. Steinmetz, Stability of the EDM-Sinking Process, Proceedings of the International Symposium on Electromachining (ISEM XII), Aachen, Germany, 11-13 May 1998. VDI-Berichte 1405, VDI Verlag Düsseldorf, 215-223

[3] A.A. Khan, Electrode wear and material removal rate during EDM of aluminum and mild steel using copper and brass electrodes, Int. J. Adv. Manuf. Technol., 39 (2000) 482-487

DOI: 10.1007/s00170-007-1241-3

[4] R. Kern, Sinker electrode material selection, available at http://www.edmtodaymagazine.com/ AAweb2_2010/TechTips2010/TechTips2008/TechTipsM-J-8.pdf, accessed at 28.10.(2011)

[5] B.A. Artamonov, A.L. Vishnitskiy, I.S. Volkov, A.V. Glazkov, Dimensional electrical machining of metals. Handbook (in Russian), Vysshaia shkola, Moscow, (1978)

[6] G. Creţu, Fundamentals of the experimental research. Laboratory handbook (in Romanian), Technical University "Gheorghe Asachi", Iaşi (Romania), (1992)
