Applications of the Electro-Contact-Discharge Machining (ECoDM) and the Analysis of Different Process Parts

Abstract:

The Electro-Contact-Discharge Machining (ECoDM) is a hybrid process composed of Electrical Discharge Machining (EDM), Arc Discharge Machining (ADM), Contact Heating Proc-ess (CoHP), and Mechanical Machining (MM). The article presents a comparison of different ap-plications and the different influence of the machining parts for a necessary result. The application field ranges from ECoDM-Cutting to the cleaning of railway tracks. The analysis of the different processing parts is necessary for monitoring the process parameters (electrical and mechanical). An advantage of the ECoDM is the cutting of electric-conductive and partial electric-non-conductive materials. The application field is not high-precise machining but rather recycling and pre-working processing. The examples show that the focal point is not the process energy source, but the selec-tion of the processing parts through the analysis of the voltage curve and/or the current curve.

• Periodical: Key Engineering Materials (Volumes 504-506)
• Pages: 1195-1200
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.504-506.1195
• Online since: February 2012
• Authors: Hans Peter Schulze
• Keywords: Arc Erosion, Field-Breakdown, Heat-Breakdown, Hybrid Machining, Spark Erosion

References

[1] H.-P. Schulze, Multiple combination of conventional and nonconventionaö processes, Int. Journal of material forming. 3 (2010), 1, 1087-1090.

[2] H.-P. Schulze, Die Elektrokontaktentladung (EDCM) – ein elektrothermisches Verfahren zur Recyclingvorbereitung, VDI-Berichte Nr. 1021, 1993, 459-462.

[3] H.-P. Schulze, M. Buhlan, F. Kubitz, M. Witte, EK-Schleifen von Kontaktstellen: Schmutz ist kein Hindernis, Schweizer Maschinenmarkt, 1990, 32, 71-76.

[4] H.-P. Schulze, T. Pape, Ausnutzung der unterschiedlichen Entladungserscheinungen für die Hochleistungsbearbeitung von hochfesten Materialien, 40. Int. Wiss. Kolloquium Ilmenau, 1995, Tagungsband 4, 123-128.

[5] H. Otto, Untersuchungen zur Anwendbarkeit des EKB zur Herstellung von Schaltverbindungen an Kupferlackdrähten, Diplomarbeit, TU Dresden 1990.

[6] H.-P. Schulze, O. Geißenhöner, Wirtschaftlichkeit der Elektrobearbeitung (EKB) gegenüber spanenden Trennverfahren, Wiss. Z. Techn. Universität Magdeburg, 33 (1989), 71-76.

[7] H.-P. Schulze, U. Werner, Theory of Electric-Contact Discharge Machining (ECDM) and ist application in heavy-duty processes. Proceedings of ISEM X, 1992, 647 – 653.
