Intelligent Metal Detector

Abstract:

Humanitarian demining is a matter of high interest, but metal contamination and magnetic soils reduce the sensitivity of metal detectors. The soil contamination also increases the numbers of false alarms which, in some areas, account for as much as 99.9 % of all alarms. The decrease of false alarms is therefore attractive. Our solution is capable to be adapted and utilized with current professional metal detectors. Essentially it consists of several modules with modular structure, where the master module is always necessary in all applications and the navigation module has to be connected in cases where position estimation is required. Searching part of the detector is able to work in continuous wave mode with variable excitation signal and the possibility to utilize more carrier frequencies. Furthermore, the modular structure can use different search heads available on the market as well as heads developed for special purposes. The modular metal and mine detector described is capable to detect not only unexploded ordnance and explosive remnants of wars, but also pipes and wires in walls and floors indoor which is useful property during not only buildings reconstructions.

• Periodical: Key Engineering Materials (Volume 543)
• Pages: 133-136
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.543.133
• Online since: March 2013
• Authors: Petr Nováček, Jakub Svatoš
• Keywords: De-Mining, Intelligent System, Metal Detection, Metal Discrimination, Navigation, Signal Processing

References

[1] A. Lewis, T. Bloodworth, D. Guelle and A. Smith. Metal-detector handbook for humanitarian demining. (2003).

[2] Metal detector, in particular mine detector, G. Kellermann. 09/04; 2005/01/08). US Patent 7265551 , (2007).

[3] P. Ripka, A. M. Lewis and J. Kubik. Mine detection in magnetic soils. Sens. Lett. 5(1), pp.15-18. (2007).

[4] Metal Detector Distinguishing Between Different Metals By Using A Bias Circuit Actuated By The Phase Shifts Caused By The Metals, R. Gardiner. 01/02). Available: http: /www. directorypatent. com/US/3872380. html, (1974).

[5] J. Svatos, J. Vedral and P. Fexa. Metal detector excited by frequency-swept signal. Metrol. Meas. Syst. 18(1), pp.57-67. (2011).

DOI: 10.2478/v10178-011-0006-3

[6] P. Novacek, P. Ripka, O. Pribula and J. Fischer. Mine detector with discrimination ability. JEE 61(7), pp.141-143. (2010).

[7] Schiebel. ATMID all Terrain Mine Detector Maintenance Manual MT5001/16/010E (2003).

[8] P. Novacek, J. Rohac and P. Ripka. Complex markers for a mine detector. Magnetics, IEEE Transactions on 48(4), pp.1489-1492. (2012).

DOI: 10.1109/tmag.2011.2172933

[9] M. Reinstein, J. Rohac and M. Sipos. Improving performance of a low-cost AHRS. Acta Avionica X(16), pp.132-137. (2008).
