Study and Fabrication of Multi-Band Filter Film on ZnS Substrate

Abstract:

In order to satisfy the special requirements of IR optical instrument, multi-band filter film on the substrate of ZnS is deposited by adopting electron beam vacuum depositing method with the ion assistant deposition technology. At incident angle of 0°～25°, 660nm high reflection and 1064nm and 3～5μm high transmission are realized. ZnS and YbF3 are selected as the high and low refractive index materials, and the film structure prepared easily is getting by optimizing the film system design curve ceaselessly. The precision of thickness control has been improved by adjusting film process parameters and improving film thickness control methods. The adhesion and firmness of film and substrate has been increased by pre-coating and mixed evaporation technology, and the laser induced damage threshold of film has been improved with vacuum annealing. The deposited film can endure the environmental tests such as rain pour, salt fog, and high and low temperature etc, and meet its practical requirement.

• Periodical: Key Engineering Materials (Volume 552)
• Pages: 147-151
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.552.147
• Online since: May 2013
• Authors: Jing Zhang, De Gui Sun, Xiu Hua Fu, Dong Mei Liu
• Keywords: Filter Film, Firmness, Ion Assistant Deposition, Laser Induced Damage Threshold

References

[1] Gong Dawei, Fu Xiuhua et al..Design and manufacture of infrared double waveband laser filter films[J].China Optics, 2011,4（3）：293-296.

[2] Wang Yizhe, Zhou Furong,Zhang Fengshan.Design and fabrication of wide three-band infrared antireflection coatings for Ge window from 3.5-12.5μm[J].Optics ＆Optoelectronic Technology,2005,3(1):32-34.

[3] Fu Xiu hua, Jiang Huilin, Fu Xinhua et al .. Study on multiwaveband infrared antireflection and protection film [ J ] .Acta Armamentarii, 2007, 28( 10) : 1183~ 1184.

[4] Pan Yongqiang, Hang Lingxia, Liang Haifeng et al. . Ultrabroadband and hard infrared antireflection coatings on ZnSe f or 2~ 16μm[ J] . Acta Optica Sinica , 2010, 30(4): 1201~ 1204.

DOI: 10.3788/aos20103004.1201

[5] R.Anton, H.Hagedorn, A.Schnellbbuegel et al..Ion assisted deposition of high quality thorium-free antireflection coatings for high-power CO2 lasers[C].SPIE,1993,2114:288-296.

DOI: 10.1117/12.180945

[6] Zhang Da-wei, He Hong-bo, Shao Jian-da et al. Preparation of high power laser films based on ion beam assisted deposition[J].Laser Technology,2008,32(1):57-60.

[7] Li Shou-zhong , Yang Yi-min, Huang Liang-pu et al. Research for working stability of Kaufman ion sources[ J] .Optical Instruments, 1999,21( 4-5):44-46.

[8] Jiang Xiao- dong, Huang Zu-xin, Ren Huan, et al. Study of laser conditioning process for optical films. High Power L a se r and Particle Beams , 2002, 14( 3) : 321-324.
