Development of a Nanomanipualtion System for Handling Nanowires

Abstract:

A compact and versatile nanomanipulation platform and its dirve-control system are being developed. This nanomanipulation sytem is aimed to handle nanowires (NWs) and fabricate nanostructures by NWs in a Scanning Electron Microscope (SEM). The excellent performance of the compact manipulator developed with corase and fine positioning in one unit has been demonstrated, which shows that the resolution is 8 nm and the steps are from 50 nm to 0.8 μm. For the power supply of the manipulator, a three-output driver is designed with a high-power integrated operational amplifier based on a mixed approach of voltage control and current control. The planar push-and-lift handling of NWs is carried out by the use of two tips to demonstrate the capability of the nanomanipulation sytem inside SEM.

• Periodical: Key Engineering Materials (Volumes 562-565)
• Pages: 1092-1097
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.562-565.1092
• Online since: July 2013
• Authors: Shi Zhong Zhang, Wei Bin Rong, Li Ning Sun
• Keywords: Amplifier, Nanohandling, Nanopositioner, Nanowire

References

[1] S. Iijima, Helical microtubules of graphitic carbon. Nature. 354(1991)56.

[2] Y. N. Xia, P. D. Yang, Y. G. Sun, Y. Wu, B. Mayers, B. Gates, Y. Yin, F. Kim, H. Yan, One-Dimensional Nanostructures: Synthesis, Characterization, and Applications, Adv. Mater. 15(2003)353.

DOI: 10.1002/adma.200390087

[3] C. N. R. Rao, G. Gundiah, F. L. Deepak, A. Govindaraj and A. K. Cheetham, Carbon-assisted synthesis of inorganic nanowires. J. Mater. Chem.. 14 (2004)440.

DOI: 10.1039/b310387k

[4] J. Rothman, M. Kläui, L. Lopez-Diaz, C. A. F. Vaz, A. Bleloch, J. A. C. Bland, Z. Cui, and R. Speaks, Observation of an onion-state and nucleation free switching in mesoscopic ring magnets, Phys. ReV. Lett. 86(2001)1098–1101.

DOI: 10.1103/physrevlett.86.1098

[5] M. Steiner, J. Nitta, Control of magnetization states in microstructured permalloy rings, Appl. Phys. Lett. 84(2004)939–941.

DOI: 10.1063/1.1646223

[6] H. G. Cha, D. K. Lee, Y. H. Kim, C. W. Kim, C. S. Lee, Y. S. Kang, Solventless nanopartical synthesis under low pressure, Inorg. Chem.. 47(2008)121–127.

DOI: 10.1021/ic701570z

[7] Y. Cui, Z. H. Zhong, D. L. Wang, et al., High performance silicon nanowire field effect transistors, Nano Letter. 3(2003)149-152.

DOI: 10.1021/nl025875l

[8] L. X. Dong, B. J. Nelson, T. Fukuda, et al., Towards nanotube linear servomotors, IEEE Trans. Autom. Sci. Eng. 3(2006)228–235.

DOI: 10.1109/tase.2006.875551

[9] T. Fukuda, M. Nakajima, Pou Liu, M. Ahmad, Bringing the nanolaboratory inside electron microscopes, IEEE Nanotechnology Magazine. 2(2008)18-31.

DOI: 10.1109/mnano.2008.925517
