Nanometer-Scale SOI Based Y-Branch Couplers for High Density Optical Integrated Circuits

Abstract:

SOI Ridge nanowire waveguide (RNW) has advantages of strong confinement of optical mode, low propagation loss, small bend radius and fully compatible with CMOS technique, etc. An ultra-compact Y-branch coupler based on SOI RNW was designed and fabricated. Based on the finite-difference beam propagation method (FD-BPM), key parameters of the coupler were analyzed. Then the device was fabricated by electron beam lithography (EBL) and inductively coupled plasma (ICP) reactive ion etching. Results showed that the propagation loss of RNW was 1.89 dB/mm, and the radiation loss of the coupler with branch angle of 30° was only 0.66 dB. Compared with traditional Y-branch coupler, the proposed structure were more promising for high density optical integrated circuits.

• Periodical: Key Engineering Materials (Volumes 562-565)
• Pages: 996-1000
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.562-565.996
• Online since: July 2013
• Authors: Zhen Zhou, Zheng Fang Dong, Li Shuang Feng, Kun Bo Wang, Yin Zhou Zhi
• Keywords: Nanowire Waveguide, Radiation Loss, Silicon-on-Insulator (SOI), Y-Branch Couplers

References

[1] H. Sasaki and N. Mikoshiba, Normalized power transmission in single mode optical branching waveguide[J], Electron. Lett., vol. 17:136~138(1981).

DOI: 10.1049/el:19810097

[2] Haihua Xu, Zhiyong Li, Yu Zhu. Silicon optical modulator with integrated grating couplers based on 0.18-μm complementary metal oxide semiconductor technology[J]. Optical Engineering. 50(4):044001(2011)

DOI: 10.1117/1.3560264

[3] Melissa Ziebell, Delphine Marris-Morini. Ten Gbit/s ring resonator silicon modulator based on interdigitated PN junctions[J]. OPTICS EXPRESS, 19(15): 14690~14695 (2011).

DOI: 10.1364/oe.19.014690

[4] Xuejun Xu, Shaowu Chen, Jinzhong Yu, Xiaoguang Tu, Realization of SOI submicrometer optical waveguide components[J], Optoelectronic Devices and Integration II(2007).

DOI: 10.1117/12.760224

[5] Soon Thor Lim, Ching Eng Png, Eng Ann Ong, and Yong Long Ang, Single mode, polarization-independent submicron silicon waveguides based on geometrical adjustments[J], Opt. Express, 15:11061~11072 (2007).

DOI: 10.1364/oe.15.011061

[6] W.P. Huang and C.L. Xu, Simulation of three-dimensional optical waveguides by a full-vector beam propagation method[J], J. Quantum Electron. 29, 2639(1993).

DOI: 10.1109/3.250386

[7] Lishuang Feng, Huilan Liu, Guanglong Wang, Huaiyong Yu. Design on waveguides coupler for integrated fiber optical gyroscope based on SOI wafer[C]. International Conference on Smart Materials and Nanotechnology in Engineering. Proc. of SPIE , Vol. 6423: 64233Q-1~7 (2007).

DOI: 10.1117/12.779846

[8] Daoxin Dai and Zhen Sheng.Numerical analysis of silicon-on-insulator ridge nanowires by using a full-vectorial finite-difference method mode solver[J]. Optical Society of America, 24(11):2853~2859(2007)

DOI: 10.1364/josab.24.002853

[9] Xuejun Xu, Shaowu Chen, Jinzhong Yu and Xiaoguang Tu. An investigation of the mode characteristics of SOI submicron rib waveguides using the film mode matching[J]. J. Opt. A: Pure Appl. Opt. 11,015508(2009).

DOI: 10.1088/1464-4258/11/1/015508
