Application of Fictitious Radius to Fatigue Life Calculations of Bending Notched Specimens

Abstract:

The paper contains an application of Neuber's fictitious radius methods to fatigue life calculations for elements with geometrical notches. FEM analysis for notched specimen with fictitious radius were performed, then results of simulations and experimental tests for smooth and notched specimens made of S355J2G1W structural steel were compared by each other. Based on simulation results, function dependence of micro structural length was determined, both for linear-elastic and elasto-plastic calculation.

• Periodical: Key Engineering Materials (Volume 598)
• Pages: 119-124
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.598.119
• Online since: January 2014
• Authors: Daniel Krzyżak, Grzegorz Robak, Tadeusz Łagoda*
• Keywords: Fatigue Life, Fictitious Radius, Microstructural Support Length, Notch Effects

References

[1] Neuber H., Über die Berücksichtigung der Spannungskonzentration bei Festigkeitsberechnungen, Konstruktion im Maschinen-Apparatte und Gerätebau, Heft 7, (1968), 245-251.

[2] Sonsino C.M., Łagoda T., Assessment of multiaxial fatigue behaviour of welded joints under combined bending and torsion by application of a fictitious notch radius International Journal of Fatigue 26, (2004), 265-279.

DOI: 10.1016/s0142-1123(03)00143-9

[3] Morgenstern C., Sonsino C.M., Hobbacher A., Sorbo F. Fatigue design of aluminium welded joints by the local stress concept with the fictitious notch radius of rf=1 mm, International Journal of Fatigue 28, (2006), 881–890

DOI: 10.1016/j.ijfatigue.2005.10.006

[4] Berto F., Zappalorto M., Fictitious notch rounding concept applied to V-notches with end holes under mode I loading, International Journal of Fracture 171, (2011), 91-98.

DOI: 10.1007/s10704-011-9626-6

[5] Biłous P., Łagoda T., Structural notch effect in steel welded joints, Materials and design, Vol.30, (2009), 4562-4564

DOI: 10.1016/j.matdes.2009.04.022

[6] Blacha Ł., Karolczuk A., Łagoda T., Modelling of stresses in welded joints under consideration of plastic strains in fatigue life calculations, Materials Testing, Vol.53, (2011), No 6, 339-343

DOI: 10.3139/120.110234

[7] Robak G., Szymaniec M., Łagoda T., The fictitious radius as a tool for fatigue life estimation of notched elements, Material Science Forum Vol. 726, (2012), 27-32.

DOI: 10.4028/www.scientific.net/msf.726.27

[8] Łagoda T., Robak G., Słowik J.: Fatigue life of steel notched elements including the complex stress state, Material and Design, Vol.51, (2013), 935-942

DOI: 10.1016/j.matdes.2013.04.087

[9] Achtelik H., Łagoda T., Macha E., Trwałość zmęczeniowa elementów gładkich i z karbem poddanych cyklicznym obciążeniom giętnoskrętnym, XI Konferencja Naukowa – Problemy Rozwoju Maszyn Roboczych vol. II, Zakopane (1998), 15-22.( in Polish)

[10] FEMAP 10.1.0 Commands help.

[11] Łagoda T., Macha E., Energy approach to fatigue under combined cyclic bending with torsion of smooth and notched specimens, Material Science Vol. 34, (1998), 630-639.

DOI: 10.1007/bf02355781
