Accuracy Analysis of Quality Factor Measurement Based on Time Domain Method for MEMS Resonators

Abstract:

To reduce the measurement cost and time, a time domain measurement method of quality factor for MEMS resonator is presented in this paper. The relation curve between quality factor and vacuum level is obtained. The results indicate that measurement error is larger under high vacuum level when the sampling frequency is lower. The reason causing the error is analyzed and measurement precision is improved by increasing the sampling frequency. The measurement results indicate time domain measurement is advisable and improvable for MEMS resonator measurement.
