Influence of Cutting Parameters and Tool Geometry on Cutting Forces and Damage on 2D and 3D Carbon/Epoxy Composites in Drilling

Abstract:

The evolution of carbon/epoxy composites use in aeronautics requires a better comprehension of the machining conditions influence on these materials. This study aim is to establish, based on the experimentation, the relationship between machining conditions and the behavior of drilled 2D and 3D carbon/epoxy composites. Two drill geometries, seam introducing and a range of cutting speed and feed have been tested. The effect of each parameter has been assessed in terms of thrust force, moment (recorded during machining) and defects (performed by macroscopic analyses and quantified using delamination factor F_d). Experimental results have shown significant influences of feed and drill geometry on delamination reduction. The use of a spur drill and a low feed generates minor defects and produces the best results. Furthermore, stitching helps reduce damage inside the hole.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 1217-1225
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.1217
• Online since: May 2014
• Authors: Yosra Turki*, Malek Habak, Raphael Velasco, Pascal Vantomme, Kamel Khellil
• Keywords: 2D Carbon/Epoxy Composites, 3D Carbon/Epoxy Composites, Cutting Force, Delamination, Drilling, Machining Conditions, Machining Defects
