Identification of Friction Law to Model Orthogonal Cutting

Abstract:

A first approach of tool-chip interface behaviour for high-speed machining modelling has been carried out by Al Brocail and 2010 and an empirical friction law has been first determined. This law has been established for high temperatures (initial sample temperature equal to 750 K) and low sliding velocities (less than 0.5 m.s^-1) and an extrapolation has been considered for higher velocities. This article intends to determine an empirical friction law for low temperatures (ambient) combined with high sliding velocities (up to 1.5m.s^-1) by means of a tribometer developed by Meresse and Al. A new experimental device is designed to carry out several tests and simulate the friction behaviour at the tool-chip interface. The experimental results are compared with a numerical model and an iterative method is used to minimize the error between experimental and numerical simulations on normal and tangential forces. This method allows to recover a Coulomb friction coefficient which is associated to local pressure, temperature and sliding velocity. The completion of several tests provides an empirical friction law for high sliding velocities and low temperatures.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 1194-1201
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.1194
• Online since: May 2014
• Authors: Yannick Senecaut, Michel Watremez*, Julien Brocail, Laurent Dubar
• Keywords: Friction Models, Machining Models, Tool-Chip Interface

References

[1] J. Brocail, M. Watremez, L. Dubar, «Identification of a friction model for modelling of orthogonal cutting, » International Journal of Machine Tools & Manufacture, pp.807-814, (2010).

DOI: 10.1016/j.ijmachtools.2010.05.003

[2] D. Meresse, M. Watremez, M. Siroux, L. Dubar et S. Harmand, «Friction and wear mechanisms study on a newly developed High Speed Tribometer, » AIP Conference Proceedings, vol. 1353, pp.1759-1764, (2011).

DOI: 10.1063/1.3589770

[3] N. Fang, «Slip-line modeling of machining with a rounded-edge tool - part II: analysis of the size effect and the shear strain-rate, » Journal of the Mechanics and Physics of Solids, vol. 51, pp.743-762, (2003).

DOI: 10.1016/s0022-5096(02)00061-3

[4] K. Ee, O. Dillon Jr. et I. Jawahir, «Finite element modelling of residual stresses in machining induced by cutting using a tool with finite edge radius, » International Journal of Mechanical Sciences, vol. 47, pp.1611-1628, (2005).

DOI: 10.1016/j.ijmecsci.2005.06.001

[5] T. Özel et E. Zeren, «A methodology to determine work material flow stress and tool-chip interfacial friction properties by using analysis of machining, » Journal of Manufacturing Science and Engineering, vol. 128, pp.119-129, (2006).

DOI: 10.1115/1.2118767

[6] C. Bonnet, F. Valiorgue, J. Rech, C. Claudin, H. Hamdi, J. Bergheau et P. Gilles, «Identification of a friction model - Application to the context of dry cutting of an AISI 316L austenitic stainless steel with a TiN coated carbide tool, » International Journal of Machine Tools and Manufacture, Vol 48, pp.1211-1223, (2008).

DOI: 10.1016/j.ijmachtools.2008.03.011

[7] F. Zemzemi, J. Rech, W. Ben Salem, A. Dogui et P. Kapsa, «Identification of a friction model at tool/chip/workpiece interfaces in dry machining of AISI4142 treated steels, » Journal of Materials Processing Technology, vol. 209, pp.3978-3990, (2009).

DOI: 10.1016/j.jmatprotec.2008.09.019

[8] J. Rech, C. Claudin, E. D'Eramo, Identification of a friction model - Application to the context of dry cutting of an AISI 1045 annealed steel with a TiN-coated carbide tool, Tribology International 42, pp.738-744, (2009).

DOI: 10.1016/j.triboint.2008.10.007

[9] H. Ben Abdelali, C. Claudin, J. Rech, W. Ben Salem, P. Kapsa et A. Dogui, «Experimental characterization of friction coefficient at the tool-chip-workpiece interface during dry cutting of AISI1045, » Wear, 286-287, pp.108-115, (2012).

DOI: 10.1016/j.wear.2011.05.030

[10] M. Watremez, D. Meresse, L. Dubar et J. Brocail, «Finite element modelling of orthogonal cutting: sensitivity analysis of material and contact parameters, » International Journal of Simulation and Process Modelling, vol. 7, pp.262-274, (2012).

DOI: 10.1504/ijspm.2012.049820

[11] S. Jaspers et J. Dautzenberg, «material behaviour in conditions similar to metal cutting: flow stress in the primary shear zone, » Journal of Materials Processing Technology, vol. 122, pp.322-330, (2002).

DOI: 10.1016/s0924-0136(01)01228-6

[12] P. Rosakis, A. Rosakis, G. Ravichandran et J. Hodowany, «A thermodynamic internal variable model for the partition of plastic work into heat and stored energy metals, » Journal of the Mechanics and the Physics of Solids, vol 15, pp.581-607, (2000).

DOI: 10.1016/s0022-5096(99)00048-4

[13] V. Kalhori, «Modeling and simulation of mechanical cutting, » PhD thesis, University of Lunea Tekniska, (2001).

[14] W. Grzesik et P. Nieslony, «Physics based on modelling of interface temperatures in machining with multiplayer coated tools at moderate cutting speeds, » International Journal of Machine Tools & Manufacture, vol 44, pp.889-901, (2004).

DOI: 10.1016/j.ijmachtools.2004.02.014
