Prediction of Post-Machining Distortion Due to Residual Stresses Using FEM and a Massive Removal Approach

Abstract:

In aeronautics weight reduction of aircrafts has become one of the main objectives. This has led to the fact that a majority of the aeronautical parts made from aluminium are large monolithic parts (to avoid the use of assembling systems like rivets and screws). The manufacturing of these aeronautic parts, especially the structural parts, is usually performed by machining. On large aluminium aeronautical parts, the main factor which can lead to non-compliance of a part is the re-equilibrium of the initial residual stresses inside the workpiece during the machining process. In this paper, an example of multi-sided machining of a part made of AIRWARE^® 2050 alloy is realised. Simulations of the machining of this part have been performed using a specific finite element tool which has been specially developed to predict the distortion due to the redistribution of these initial residual stresses during machining. Results numerically obtained are then compared with experimental results, showing a good agreement.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 1159-1165
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.1159
• Online since: May 2014
• Authors: Xavier Cerutti*, Katia Mocellin
• Keywords: AIRWARE® 2050 Alloy, Distortion, Finite Element Method (FEM), Machining, Residual Stress

References

[1] Yang, Y., Li, M., and Li, K. (2013) The International Journal of Advanced Manufacturing Technology pp.1-9.

[2] Das, S. and Chandra, U. (1999) Residual Stress and Distortion, in Handbook of Aluminum Metallurgy: Processes and Equipment, volume 1, G. E. Totten and D. S. Mackenzie, Marcel Dekker, Inc., New York, NY.

[3] Sim, W. (2010) International Journal of Microstructure and Materials Properties 5, 446-455.

[4] Chenot, J. (1989) In Computational Plasticity: Models, Software and Applications Proceedings of the Second International Conference Held in Barcelona, Spain : pp.793-816.

[5] Ma, K., Goetz, R., and Svrivatsa, S. (2010) ASM Handbook, Metals Process Simulation 22B, 386-407.

[6] Lequeu, P., Smith, K., and Danielou, A. (2010) Journal of Materials Engineering and Performance 19(6), 841-847.

[7] Cerutti, X., Hassini, S., Duc, E., and Mocellin, K. (2013) volume 768 - 769, Proceedings of the International Conference on Residual Stresses 9 (ICRS 9) : pp.398-405.

DOI: 10.4028/www.scientific.net/msf.768-769.398

[8] Coupez, T., Digonnet, H., and Ducloux, R. (2000) Applied Mathematical Modelling 25(2), 153 - 175.

DOI: 10.1016/s0307-904x(00)00045-7

[9] Fourment, L., Chenot, J. L., and Mocellin, K. (1999) International Journal for Numerical Methods in Engineering 46(9), 1435-1462.
