Effects of the Flow Stress in Finite Element Simulation of Machining Inconel 718 Alloy

Abstract:

Inconel 718 superalloy is one of the difficult-to-machine materials which is employed widely in aerospace industries because of its superior properties such as heat-resistance, high melting temperature, and maintenance of strength and hardness at high temperatures. Material behavior of the Inconel 718 is an important challenge during finite element simulation of the machining process because of the mentioned properties. In this regard, various constants for Johnson–Cook’s constitutive equation have been reported in the literature. Owing to the fact that simulation of machining process is very sensitive to the material model, in this study the effect of different flow stresses were investigated on outputs of the orthogonal cutting process of Inconel 718 alloy. For each model, the predicted results of cutting forces, chip geometry and temperature were compared with experimental results of the previous work at the different feed rates. After comparing the results of the different models, the most suitable Johnson–Cook’s material model was indentified. Obtained results showed that the selected material model can be used reliably for machining simulation of Inconel 718 superalloy.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 1210-1216
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.1210
• Online since: May 2014
• Authors: Farshid Jafarian, Mikel Imaz Ciaran, Pedro José Arrazola, Luigino Filice*, Domenico Umbrello, H. Amirabadi

References

[1] Umbrello D., M'Saoubi R., Outeiro J.C., The influence of Johnson–Cook material constants on finite element simulation of machining of AISI 316L steel. International Journal of Machine Tools and Manufacture, 47: 462–470, (2007).

DOI: 10.1016/j.ijmachtools.2006.06.006

[2] De Mange J.J., Prakash V., Pereira J.M., Effects of material microstructure on blunt projectile penetration of a nickel-based super alloy. International Journal of Impact Engineering. 36: 1027–1043, (2009).

DOI: 10.1016/j.ijimpeng.2009.01.007

[3] Wang X., Huang C., Zou B., Liu H., Zhu H., Wang J., Dynamic behavior and a modified Johnson–Cook constitutive model of Inconel 718 at high strain rate and elevated temperature. Journal of Materials Science & Engineering A. 580: 385–390, (2013).

DOI: 10.1016/j.msea.2013.05.062

[4] Klocke F., Lung D., Buchkremer S., Inverse Identification of the Constitutive Equation of Inconel 718 and AISI 1045 from FE Machining Simulations. 14th CIRP Conference on Modeling of Machining Operations, Procedia CIRP. 8: 212–217, (2013).

DOI: 10.1016/j.procir.2013.06.091

[5] Pereira J.M., Lerch B.A., Effects of heat treatment on the ballistic impact properties of Inconel 718 for jet engine fan containment applications. International Journal of Impact Engineering. 25: 715–733, (2001).

DOI: 10.1016/s0734-743x(01)00018-5

[6] Mitrofanov A. V, Babitsky V.I., Silberschmidt V.V., Thermomechanical finite element simulations of ultrasonically assisted turning. Computational Materials Science. 32: 463–471, (2005).

DOI: 10.1016/j.commatsci.2004.09.019

[7] Lorentzon J., Jarvstrat N., Josefson B.L., Modelling chip formation of alloy 718. Journal of Materials Processing Technology 209: 4645–4653, (2009).

DOI: 10.1016/j.jmatprotec.2008.11.029

[8] Ozel T., Llanos L., Soriano J., Arrazola P.J., 3D finite element modelling of chip formation process for machining Inconel 718: Comparison of FE software predictions. Journal of Machining Science and Technology, 15: 21–46, (2011).

DOI: 10.1080/10910344.2011.557950

[9] Malakizadi A., Cedergren S., Surreddi K. B, Nyborg L., A methodology to evaluate the machinability of Alloy 718 by means of FE simulation. International Conference on Advanced Manufacturing Engineering and Technologies. (2013).

[10] Del Prete A., Filice L., Umbrello D., Numerical simulation of machining nickel-based alloys. Procedia CIRP, 8: 539-544, (2013).

DOI: 10.1016/j.procir.2013.06.147
