The Influence of Equivalent Contact Area Computation in Extended Node to Surface Contact Elements

Abstract:

This article aims at extending the node to surface formulation for contact problems withan area regularization as proposed by [1]. For that purpose, two methods are proposed to computethe equivalent contact area attributed to each slave node. The first method, which is based on a geo-metrical approach through force equivalence, is an original extension of the one proposed in [1] fortwo-dimensional contact problems, i.e. plane stress and plane strain state, to the axisymmetric mod-elling context. The second method relies on an energy consistent way obtained through the virtualwork principle and the same expression for the equivalent contact area as the one originally cited in[2] is then recovered. First, the node to surface strategy with area regularization is introduced and theaforementioned methods for the equivalent contact area are presented in detail and compared. After-wards a consistent linearization technique is applied to achieve a quadratic convergence rate in theNewton Raphson iterative procedure used to solve the non-linear equilibrium equations of the under-lying finite element model. Finally, two axisymmetric numerical examples are provided in order tocompare the aforementioned equivalent contact area evaluations and to demonstrate the performanceand the robustness of the consistent approach especially in the neighbourhood the revolution axis.

• Periodical: Key Engineering Materials (Volume 618)
• Pages: 1-22
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.618.1
• Online since: July 2014
• Authors: Gaetan Wautelet*, Jean Philippe Ponthot
• Keywords: Area Regularization, Axisymmetric, Contact Mechanics, Finite Element Method (FEM), Friction-Less, Node to Surface, Penalty Method

References

[1] G. Zavarise and L. De Lorenzis: International Journal for Numerical Methods in Engineering Vol. 79(4) (2009), pp.379-416.

[2] S. Stupkiewicz: International Journal for Numerical Methods in Engineering Vol. 50(3) (2001), pp.739-759.

[3] T. A. Laursen: Computational Contact and Impact Mechanics: Fundamentals of Modeling Interfacial Phenomena in Nonlinear Finite Element Analysis (Springer-Verlag, Berlin Heidelberg 2002).

[4] P. Wriggers: Computational Contact Mechanics (Springer-Verlag, Berlin Heidelberg 2006).

[5] Z.-H. Zhong: Finite Element Procedures for Contact-Impact Problems (Oxford University Press, New York 1993).

[6] G. Zavarise, P. Wriggers, E. Stein and B. A. Schrefler: International Journal for Numerical Methods in Engineering Vol. 35(4) (1992), pp.767-785.

[7] B. A. Schrefler and G. Zavarise: Computer-Aided Civil and Infrastructure Engineering Vol. 8(4) (1993), pp.299-308.

[8] G. Zavarise, M. Borri-Brunetto and M. Paggi: Wear Vol. 257(3-4) (2004), pp.229-245.

DOI: 10.1016/j.wear.2003.12.010

[9] L. Anand: Computational Mechanics Vol. 12(4) (1993), pp.197-213.

[10] S. Stupkiewicz and Z. Mróz: Wear Vol. 231(1) (1999), pp.124-138.

[11] F. B. Belgacem, P. Hild and P. Laborde: Mathematical and Computer Modelling Vol. 28(4-8) (1998), pp.263-271.

[12] M. A. Puso and T. A. Laursen: Computer Methods in Applied Mechanics and Engineering Vol. 193(6-8) (2004), pp.601-629.

[13] A. Popp, M. W. Gee and W. A. Wall: International Journal for Numerical Methods in Engineering Vol. 79(11) (2009), pp.1354-1391.

[14] P. Papadopoulos and R. L. Taylor: Computer Methods in Applied Mechanics and Engineering Vol. 94(3) (1992), pp.373-389.

[15] P. Papadopoulos and R. L. Taylor: Computers & Structures Vol. 46(6) (1993), pp.1107-1118.[16] G. Zavarise and P. Wriggers: Mathematical and Computer Modelling Vol. 28(4-8) (1998), pp.497-515.

[17] R. L. Taylor and P. Papadopoulos, in: Nonlinear Computational Mechanics, edited by P. Wriggers and W. Wagner, Springer-Verlag, Berlin (1991), pp.690-702.

[18] Information on http://metafor.ltas.ulg.ac.be.

[19] D.-T. Nguyen, G. Rauchs and J.-P. Ponthot: Journal of Computational and Applied Mathematics Vol. 246(0) (2013), pp.195-205.

[20] J. C. Simo, P. Wriggers, and R. L. Taylor: Computer Methods in Applied Mechanics and Engineering Vol. 50(2) (1985), pp.163-180.

[21] G. Zavarise and L. De Lorenzis, in: Trends in Computational Contact Mechanics, edited by G. Zavarise and P. Wriggers, volume 58 of Lecture Notes in Applied and Computational Mechanics, Springer-Verlag, Berlin Heidelberg (2011), pp.79-100.

DOI: 10.1007/978-3-642-22167-5

[22] K. J. Bathe: Finite Element Procedures (Prentice-Hall, New Jersey 1996).

[23] P. Wriggers: Nonlinear Finite Element Methods (Springer-Verlag, Berlin Heidelberg 2008).

[24] T. Belytschko, B. Moran and W. K. Liu: Nonlinear Finite Elements for Continua and Structures (John Wiley & Sons, England 2000).

[25] J.-P. Ponthot: PhD thesis, University of Liège (1995).

[26] R. W. Ogden : Non-Linear Elastic Deformations (Dover Publications, New York 1997).

[27] G. Zavarise, L. De Lorenzis and R. L. Taylor: Computer Methods in Applied Mechanics and Engineering Vol. 205-208 (2012), pp.91-109.

DOI: 10.1016/j.cma.2011.02.018

[28] S. Timoshenko and J. N. Goodier: Theory of Elasticity (McGraw-Hill Book Company, New York 1951).

[29] K. Johnson: Contact Mechanics (Cambridge University Press, Cambridge 1987).
