Investigation of Scar Formation in Fine Blanking Processes and their Prediction in 3D ALE Simulations

Abstract:

Scar formation in fine blanking was investigated by means of a particularly developed fine blanking tool and experimental evidence about significant the process parameters chamfer size of the blanking tools, V-Ring usage and clearance is given. Furthermore, a special purpose Finite Element code using the Arbitrary-Lagrange-Eulerian method with a process specific mesh generation is demonstrated and used for the determination of relevant parameters for prediction crack formation in 3D fine blanking simulations. The simulations shown, that a commonly used description of fracture strain as a function of stress and deformation state is not sufficient. In order to simulate scar occurrence on the blanking surface, the significant increase of fracture strain due to temperature rise because of plastic heat generation has to be taken into account. A possible way of measuring the temperature effect was shown in torsion tests at different initial temperature levels.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 1181-1190
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.1181
• Online since: September 2014
• Authors: Thomas Wesner*, Pavel Hora
• Keywords: ALE, Ductile Fracture, Fine Blanking, Material Modelling

References

[1] Herres W. -U., : Prozessüberwachung beim Feinschneiden: Werkzeugkräfte und akustische Emissionen als Mittel zur Qualitätskontrolle, (1992).

[2] Wesner T., Manopulo N. and Hora P., : Failure prediction methods in 3D ale fine blanking simulations in IDDRG 2013 Conference Proceedings, p.235–240, (2013).

[3] Manopulo N., Hora P. and Wegener K., : An ALE based FE formulation for the 3D simulation of the fineblanking process, (2011).

DOI: 10.1063/1.3589681

[4] Freudenthal A. M., : The Inelastic Behavior of Engineering Materials and Structures, (1950).

[5] Oyane M., Sato T., Okimoto K. and Shima S., : Criteria for ductile fracture and their applications, Journal of Mechanical Working Technology 4, p.65–81, Apr. (1980).

DOI: 10.1016/0378-3804(80)90006-6

[6] Cockcroft M. G. and Latham D. J., : A Simple Criterion of Fracture for Ductile Metals, (1966).

[7] Johnson G. R. and Cook W. H., : Fracture characteristics of three metals subjected to various strains, strain rates, temperatures and pressures, Engineering Fracture Mechanics 21, p.31–48, (1985).

DOI: 10.1016/0013-7944(85)90052-9

[8] Hora P., Tong L. and Berisha B., : Stress Limit Model With Deformation Dependent Damage For Failure Prediction In Bulk Forming Processes in AIP Conference Proceedings, p.1401–1406, (2007).

DOI: 10.1063/1.2741005

[9] Bai Y. and Wierzbicki T., : A new model of metal plasticity and fracture with pressure and Lode dependence, International Journal of Plasticity 24, p.1071–1096, Jun. (2008).

DOI: 10.1016/j.ijplas.2007.09.004

[10] Gurson A. L., : Continuum Theory of Ductile Rupture by Void Nucleation and Growth: Part I--Yield Criteria and Flow Rules for Porous Ductile Media, Journal of Engineering Materials and Technology 99, p.2–15, Jan. (1977).

DOI: 10.1115/1.3443401

[11] Rousselier G., : Ductile fracture models and their potential in local approach of fracture, Nuclear Engineering and Design 105, p.97–111, Dec. (1987).

DOI: 10.1016/0029-5493(87)90234-2

[12] Lemaitre J., : A Continuous Damage Mechanics Model for Ductile Fracture, Journal of Engineering Materials and Technology 107, p.83, (1985).

DOI: 10.1115/1.3225775

[13] Hora P., Tong L., Berisha B. and Karadogan C., : Damage dependent stress limit model for failure prediction in bulk forming processes, International Journal of Material Forming, Oct. (2010).

DOI: 10.1007/s12289-010-1002-y

[14] Brozzo P., Deluca B. and Rendina R., : A new method for the prediction of the formability limits of plastic sheets in Proceedings of the 7th Biennial Congress of the IDDRG, Netherland, (1972).
