Investigation of the Shape of a Cruciform Biaxial Tensile Specimen Intended for a Combination of Plane Strain Tensile States

Abstract:

This study investigates the shape of a cruciform specimen that is stretched in the normal direction of the minimum cross section using FEM. In addition, plane strain tensile states exist in the measurement region in order to determine the forming limit diagram not by an arbitrary stress ratio but by the strain ratio. We propose two types of cruciform specimens. One is a flat-type cruciform specimen, which has deep slits in the middle of the arm region in the width direction. The other specimen is a reduced measurement region type, which also has deep slits as well as a shape that is a biaxial combination of two plane strain tensile specimens. We analyze equibiaxial tensile tests of these two proposed cruciform specimen types using FEM.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 308-313
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.308
• Online since: September 2014
• Authors: Hayato Usui*, Takashi Iizuka
• Keywords: Biaxial Tensile Test, Cruciform Specimen, FEM, Plane Strain

References

[1] T. Kuwabara, A. Van Bael, E. Iizuka: Measurement and Analysis of Yield Locus and Work Hardening Characteristics of Steel Sheets with Different r-values, Acta Materiaria, 50 (2002) 3717-3729.

DOI: 10.1016/s1359-6454(02)00184-2

[2] T. Kuwabara: Advances of Plasticity Experiments on Metal Sheets and Tubes and Their Applicaitions to Consititutive Modeling, Numisheet 2005, Volume A (2005) 20-39.

[3] E. Shiratori, K. Ikegami, H. Okano: The Influence of Prestrain on Subsequent Yield Surfaces, Bulletin of JSME, Vol. 11, No. 45 (1968) 413-418.

DOI: 10.1299/jsme1958.11.413

[4] T. Hakoyama, T. Kuwabara: Biaxial Tensile Test of High Strength Steel Sheet for Large Plastic Strain Range, Key Engineering Materials, 504-506 (2012) 59-64.

DOI: 10.4028/www.scientific.net/kem.504-506.59

[5] M. Strano, T. Altan: An inverse energy approach to determine the flow stress of tubular materials for hydroforming applications, Journal of Materials Processing Technology, 146 (2004) 92-96.

DOI: 10.1016/j.jmatprotec.2003.07.016

[6] Y. Hanabusa, H. Takizawa, T. Kuwabara: Evaluation of Accuracy of Stress Measurements Determined in Biaxial Stress Tests with Cruciform Specimen Using Numerical Method, Steel Research Int., 81 (2010) 1376-1379.

[7] A. Makinde, L. Thibodeau, K.W. Neale: Development of an Apparatus for Biaxial Testing Using Cruciform Specimens, Experimental Mechanics, 32 (1992) 138-144.

DOI: 10.1007/bf02324725

[8] J.P. Boehler, S. Demmerle, S. Koss: A New Direct Biaxial Testing Machine for Anisotropic Materials, Experimental Mechanics, 34 (1994) 1-9.

DOI: 10.1007/bf02328435
