Physical and Numerical Modelling of Wire Drawing Process of Mg Alloys in Heated Dies Accounting for Recrystallization

Abstract:

Magnesium-calcium alloys with increased bio-compatibility are applied in medicine for sake of high compatibility and solubility in human body. Production of surgical threads to integration of tissue may be one of the applications of those types of alloys. A new manufacturing process of thin wires made of biocompatible Mg alloys, including drawing in heated dies, was developed in Authors previous works. Conducting drawing process in conditions, in which recrystallization occurs, is the basis of the process. This allows for multi-pass drawing without intermediate annealing. Control of recrystallization after every pass using experimental method is complex so numerical simulation seems to be a rational method to design the process parameters. The purpose of the paper is developing a mathematical model of recrystallization for MgCa08 alloy, its implementation into the finite element (FE) code that simulates wire drawing and experimental verification of the numerical calculations. The first part of work was focused on the development of mathematical model of wire drawing process of Mg alloys in heated die. Proposed model takes into account thermal phenomena in the wire and in the die, plastic flow of the material, stress-strain state and recrystallization. The fracture criterion was implemented into FE code to eliminate the possibility of damage. The second part of the work was focused on experiments including upsetting and tensile tests for calibration of recrystallization and fracture models. Recrystallization model was calibrated on the basis of flow curves only what is a limitation. Therefore, experimental wire drawing on drawing bench developed by the Authors was the final stage of the work performed to validate the model. Recrystallization during wire drawing was studied. The developed computer program enables prediction of the recrystallization kinetics during wire drawing in heated die for MgCa08 alloy. The model of static and dynamic recrystallization of this alloy and complex model of the drawing process were proposed in this work, as well.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 651-658
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.651
• Online since: September 2014
• Authors: Andrij Milenin*, Piotr Kustra, Maciej Pietrzyk
• Keywords: Drawing Process, Fracture Model, Magnesium Alloy, MgCa08, Recrystallization

References

[1] F.W. Bach, R. Kucharski, D. Bormann, Magnesium compound structures for the treatment of bone defects, Engineering of Biomaterials, 56-57 (2006) 58-61.

[2] J.M. Seitz, E. Wulf, P. Freytag, D. Bormann, F.W. Bach, The Manufacture of resorbable suture material from magnesium, Adv. Eng. Mater. 12 (2010) 1099-1105.

DOI: 10.1002/adem.201000191

[3] A. Milenin, J.M. Seitz, Fr.W. Bach, D. Bormann, P. Kustra, Production of thin wires of magnesium alloys for surgical applications, Wire Journal Int., 6 (2011) 74-83.

[4] A. Milenin, P. Kustra, Mathematical model of warm drawing process of magnesium alloys in heated dies, Steel Res. Int. 81 (2010) 1251-1254.

[5] A. Milenin, P. Kustra, Numerical and experimental analysis of wire drawing for hardly deformable biocompatible magnesium alloys, Arch. Metall. Mater. 58 (2013) 55-62.

DOI: 10.2478/v10172-012-0150-0

[6] A. Milenin, P. Kustra, D. Byrska-Wojcik, FEM-BEM Code for the multiscale modeling and computer aided design of wire drawing technology for magnesium alloys, Adv. Eng. Mater. 2013, doi: 10. 1002/adem. 201300279.

DOI: 10.1002/adem.201300279

[7] D. Szeliga, M. Pietrzyk, Testing of the inverse software for identification of rheological models of materials subjected to plastic deformation, Arch. Civ. Mech. Eng. 7, 1 (2007) 35-52.

DOI: 10.1016/s1644-9665(12)60003-x

[8] C.M. Sellars, Physical Metallurgy of Hot Working, International conference of Hot Working and Forming Processes, The Metals Society, London, 1979, 3-15.

[9] S. Wang, S.B. Kang, J.H. Cho, Effect of hot compression and annealing on microstructure evolution of ZK60 magnesium alloy, Journal of Materials Science, 44 (2009) 5475-5485.

DOI: 10.1007/s10853-009-3762-7
