Structure Design of Large Travel One-Arm Bridge Type Z-Axis Nano-Positioning Stage

Abstract:

In some areas such as micro-mechanical, ultra-precision machining, nanotechnology, the high-precision positioning and very fine vertical scanning motion are needed urgently. Therefore, the Z-axis micro-displacement driving control technology has become the key technology in these areas. The piezoelectric ceramics actuator and stepper motor were integrated into hybrid linear actuator in Z-axis nanopositioning stage, and this can simplify the structure of the drive system. By calculating the gravity center of the vertical scanning system, and using single counterweight, a new one-arm bridge type structure was built. Appropriate tension and current sensors were also equipped in order to real-time monitor the drive status. It is feasible to balance the weight with this simplified system structure, and also guarantee the driving control accuracy of nanopositioning stage. Besides, in the structural design, the Abbe error can be reduced greatly by placing the stage center, grating ruler and displacement measurement centerline on the same line with grating reading head. The driving travel of nanopositioning stage is 150mm, and driving resolution is 1nm. The designing method introduced gives a scientific method and practical reference for the development of z-axis driving control system.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 1064-1071
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.1064
• Online since: May 2015
• Authors: Wei Fan*, Zhong Shen Li, Shao Yin Jiang
• Keywords: Abbe Error, Large Travel, Nanopositioning Stage, One-Arm Bridge Type, Structure Design

References

[1] Yung-Tien Liu, Rong-Fong Fung, Tai-Kun Huang. Dynamic responses of a precision positioning table impacted by a soft-mounted piezoelectric actuator Precision Engineering 28 (2004) 252–260.

DOI: 10.1016/j.precisioneng.2003.10.005

[2] Kazuhiro Takahashi，Makoto Mita，Hiroyuki Fujita，et al. A high fill-factor comb-driven XY-stage with topological layer switch architecture[J]．IEICE Electronics Express，2006，3（9）：197-202.

DOI: 10.1587/elex.3.197

[3] Gu Lei ，Li Xinxin ，Bao Haifei ，et al. Single-waferprocessed nano-positioning XY-stages with trenchsidewall micromachining technology［J］．J Micromech Microeng， 2006 16（7）：1349-1357.

DOI: 10.1088/0960-1317/16/7/032

[4] Cox J , Miller L. The first 50 years of electronic watermarking[J]. Journal of Applied Signal Processing , 2002 , (2) : 126 —132.

[5] Kramar J A. Nanometre resolution metrology with the molecular measuring machine[J]. Measurement Science and Technology , 2005 , 16 : 212122128.

DOI: 10.1088/0957-0233/16/11/001

[6] Gred J , Rainer G, Eberhard M, et al. A nanopositioning and nanomeasuring machine : operation-measured results[J]. Nano-technology and Precision Engineering , 2004 , 2 (2) : 81284.

[7] Holmes M, Hocken R , Trumper D. The long-range scanning stage, a novel platformfor scanned2probe microscopy[J]. Precision Engineering , 2000 , 24 : 1912209.

DOI: 10.1016/s0141-6359(99)00044-6

[8] Tian YL，Shirinzadeh B，ZhangDW. A flexure-based mechanism and control methodology for ultra-precision turning operation [ J ]. Precision Engineering， 2009，33 (2) : 160 - 166.

DOI: 10.1016/j.precisioneng.2008.05.001

[9] Canudas W C，Lischinsky P． Adaptive friction compensation with partially known dynamic friction model［J］． International Journal of Adaptive Control Signal Process， 2007， 11( 1) : 65- 80.

DOI: 10.1002/(sici)1099-1115(199702)11:1<65::aid-acs395>3.0.co;2-3

[10] Kim H M，Park S H，Han S I． Precise friction control for the nonlinear friction system using the friction state observer and sliding mode control with recurrent fuzzy neural networks［J］． Mechatronics，2009，19( 6) : 805- 815.

DOI: 10.1016/j.mechatronics.2009.04.004
