Micro-Fabricated Pre-Concentrator Filled with Single-Walled Carbon Nanotubes as Adsorbent Material

Abstract:

As concentration of components in environmental gas is very low, and the available analytical instruments are not sufficiently sensitive, so that micro pre-concentrators developed for effectively concentrating components are very important and necessary. Therefore, in this work a micro pre-concentrator was fabricated for concentrating trace gas. The micro pre-concentrator with 4 parallel channels filled with Single-Walled Carbon Nanotubes (SWCNTs) as adsorbent materials was developed for concentrating volatile organic compounds (VOCs). This choice was done on the basis of the consideration: 4 parallel channels ensure that the pre-concentrator can be filled with a sufficient amount of adsorbent materials. Moreover, SWCNTs was acted as adsorbent material owing to their chemical and thermal stability, a high surface-to-volume ratio, and a large affinity to the non-polar compounds. The experimental results show that the micro pre-concentrator effectively concentrated benzene with a concentration factor of 15 and the chromatography peak broadening was also greatly compressed.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 681-686
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.681
• Online since: May 2015
• Authors: Xiao Feng Zhu, Zhan Wu Ning, Jian Hai Sun*, Tian Jun Ma, Yan Ni Zhang, Jin Hua Liu
• Keywords: Carbon Nanotubes, Concentration Factor, Micro Pre-Concentrator, PID System

References

[1] M. Martin, M. Crain, et al., Sensors and Actuators, B: Chemical, 126 (2)(2007)447-454.

[2] B. Alfeeli, M. Agah, Proceedings of IEEE Sensors, 2008, 736-739.

[3] B. Alfeeli, M. Agah, IEEE Sensors Journal , art. no. 5928373 (2011) 2756-2762.

[4] B. Alfeeli, H. Vereb, et al., Proceedings of the IEEE International Conference on Micro Electro Mechanical Systems (MEMS), art. No. 5734575(2011) 916-919.

[5] I. Voicolescu, R. A. McGill, et al., IEEE Sensors Journal, 6 (5)( 2006)1094-1103.

[6] P.R. Lewis, P. Manginell, et al., Sensors Journal, IEEE, 6(3)(2006)784-795.

[7] W.C. Tian, S.W. Pang, et al., Journal of Microelectromechanical Systems, 12 (3)(2003) 264-272.

[8] I. Gr`acia, P. Ivanov, et al., Sensors and Actuators B 132 (2008)149–154.

[9] J. Zhao, T. Luo, X. Zhang, et al., Analytical Chemistry, 84(15)( 2012) 6303-6307.

[10] M. Phillips, R.N. Cataneo, et al., Chest, 123(2003) 2115-2123.

[11] Chen X, Xu FJ, et al., Cancer, 110(4)(2007) 835-844.

[12] S. Takada, T. Nakai, et al., IEEJ Transactions on Sensors and Micromachines, 130 (6)(2010) 207-211.

[13] I. Gràcia, P. Ivanov, F. Blanco, et al., Sensors and Actuators, B: Chemical, 132 (1) (2008)149-154.

[14] Jiemin Liu, Lin Li, Chinese Journal of Analytical Chemistry, 35(6)(2007)830~834.

[15] J.H. Sun, F.Y. Guan, D.F. Cui, X. Chen, L.L. Zhang, J. Chen, Sensors & Actuators: B. Chemical, 188( 2013) 513-518.

[16] J.H. Sun, D.F. Cui, X. Chen L.L. Zhang, H. Li, J. Chromatogr. A 1291( 24 )(2013)122–128.
