A New Design of a Piezoelectric Triaxial Micro-Accelerometer

Abstract:

Accelerometer in MEMS always is made by capacitive or piezoresistive, whose dynamic response is not good, the operating frequency is narrow, and the cross-axis sensitivity is low. A new type of piezoelectric micro-accelerometer is designed, and its structure is “x” type. The sensing unit is piezoelectric PZT films, which is achieved by sol-gel method. The accelerometer is a triaxial accelerometer. The theoretical and simulation analysis is used to achieve the charge sensitivity and response frequency, and also get the optimal structural parameters. A new circuit connection is proposed to improve the sensitivity and avoid the cross-axis sensitivity. The design achieves the z-axis sensitivity with more than 40 pC/g, x, y-axis sensitivity with more than 8pC/g, and the response frequency is about 3000Hz.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 841-846
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.841
• Online since: May 2015
• Authors: Jian Yan Wang, Ting Ting Wang, Hang Guo*
• Keywords: Accelerometer, Circuit Connection, Simulation, Theotetical Analysis

References

[1] Roger De Reus, Jens Ole Gullov, and Patrick R Scheeper, Fabrication and characterization of a piezoelectric accelerometer, Journal of Micromechanics and Micraengineering. 9(1999) 123-126.

DOI: 10.1088/0960-1317/9/2/005

[2] Y. Nemirovsky, A. Nemirovsky, P. Muralt, N. Setter, Design of a novel thin-film piezoelectric accelerometer, Sensors and Actuators. 56(1996) 239-249.

DOI: 10.1016/s0924-4247(96)01324-6

[3] Korbinian Kunz, Peter Enoksson, Goran Stemme, Highly sensitive triaxial silicon accelerometer with integrated PZT thin film detectors, Sensors and Actuators. 92( 2001) 156-160.

DOI: 10.1016/s0924-4247(01)00555-6

[4] Han Geun Yu, L. Zou, K. Deng, el, Lead zirconate titanate MEMS accelerometer using interdigitated electrodes. 107(2003)26-34.

DOI: 10.1016/s0924-4247(03)00271-1

[5] Christian Carstensen Hindrichsen, Ninia S. Almind, el, Analytical Model of a PZT Thick-Film Triaxial Accelerometer for Optimum Design, IEEE SENSORS JOURNAL. 4(2009)419-429.

DOI: 10.1109/jsen.2009.2014412

[6] J. Hillenbrand, M. Kodejska, el, High-sensitivity Piezoelectret-film Accelerometers, 4(2010)1021-1027.

DOI: 10.1109/tdei.2010.5539670

[7] R.P. van Kampen, R.F. Wolffennbuttel. Modeling the mechanical behavior of bulk-micromachined silicon accelerometers, Sensors and Actuators. 64(1998)117-150.

DOI: 10.1016/s0924-4247(98)80007-1

[8] A.T. Kollias, J.N. Avaritsotis. A study on the performance of bending mode piezoelectric accelerometers [J], Sensors and Actuators, 121(2005)434-442.

DOI: 10.1016/j.sna.2005.03.014
