The Parametric Analysis of the Threshold Value Judging Mechanism in MEMS Safety and Arming Device

Abstract:

In this paper, a mechanical MEMS S&A device has been proposed. The size of the device is 10mm×13mm×0.5mm. The role of the threshold value judging mechanism is to determine the environment suffered by centrifugal force and control the sub-centrifugal slider not movement under the threshold, so as to effectively guarantee the time of long-distance arming. Through establishing the three-dimensional model of threshold value judging mechanism, establishing the force and the parameters of locking-releasing mechanism, deriving the mathematical model according to the rigid dynamic mechanics theory and establishing the finite element model by using ANSYS/LS-DYNA, appropriate threshold value judging mechanism is designed to meet two items, one item is the deformation of threshold value rod is not enough to release sub-centrifugal slider when the speed is less than 60000r/min; the other item is deformation of threshold value rod can release sub-centrifugal slider when the speed is more than 60000r/min.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 968-971
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.968
• Online since: May 2015
• Authors: Fu Fu Wang*, Wen Zhong Lou, Fang Yi Liu, Da Kui Wang, Ming Rong Zhang, Cheng Gang Xu
• Keywords: Arming Device, MEMS, Safety Device, Threshold Value Judging Mechanism

References

[1] Robinson, C. H., Wood, R. H. and Hoang, T. Q., Development of Inexpensive, Ultra-Miniature MEMSBased Safety Andarming (S&A) Device for SmallCaliber Munition Fuzes, Proceedings of 23rd ArmyScience Conference, pp.111-116 (2002).

[2] Renaud Lafont. Micro-machined or micro-engraved safety and arming device [P]. US Patent No. 0205526A1, (2009).

[3] Chopin Hua. High-g MEMS Fuzes [R]. Baltimore, USA: 56TH ANNUAL FUZE CONFERENCE, (2012).

[4] David A. Olson. Microelectromechanical Systems Ignition Safety Device [P]. US Patent No. 7971532A1, (2011).

[5] Wang Fufu, Lou Wenzhong, Wang Ying. Design and analysis of a novel locking mechanism of MEMS safety and arming device [J].  pp.856-859, 2014, Micro-Nano Technology XV.

DOI: 10.1109/nems.2013.6559841
