Nano-Structured Tungsten Carbide Coating Reduces Wear of Tooling for Extrusion and Abrasive Materials Forming

Abstract:

This paper presents the applications of advanced CVD Tungsten Carbide coating to extend the life of tooling used for forming abrasive and corrosive materials.Hardide nanostructured Tungsten Carbide coating combines high hardness (70-77Rc) with excellent toughness. Unlike other hard coatings Hardide can produce a conformal coating layer on complex-shaped tools, including internal surfaces of extrusion die cavities and moulds. In ASTM G65 test the Hardide coating abrasion resistance exceeded WC/Co (9%) cemented carbide by a factor of 4X, and D2 tool steel by 10X. Thus the coating can significantly increase the life of D2 steel tooling used for forming abrasive materials and by maintaining better dimensional tolerances and surface finish of the tool it will manufacture better quality products.The Hardide coating has enhanced resistance to corrosion and aggressive media, including acids; this makes the coating especially suitable for the tooling used in forming uPVC, PTFE and other corrosive materials.The Hardide coating has been tested on extrusion and pelletizing dies processing abrasive and corrosive slurries and typically showed a 3X increase in the life of the tooling. Similar results were achieved by the coating of powder compaction punch/die sets for pharmaceuticals tableting.

• Periodical: Key Engineering Materials (Volumes 651-653)
• Pages: 467-472
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.651-653.467
• Online since: July 2015
• Authors: Yuri Zhuk*
• Keywords: Coat Internals, Corrosion Resistant, CVD, Hard Coating, Tooling Protection, Tungsten Carbide, Wear Resistant

References

[1] Preferred and Alternative Methods for Estimating Air Emissions from Plastics Products Manufacturing, published by the US Environmental Protection Agency in (1998).

[2] HARDIDE™ CVD Coatings Protect Internal Surfaces and Complex Shaped Parts against wear, erosion and corrosion, Advanced Materials & Processes, August 2011, pp.21-24.

[3] HARDIDE™ – Advanced Wear-Resistant CVD Coating, Surface World, Sept. 2008, pp.34-40.

[4] ASTM G65-94, Standard test for measuring abrasion using the dry sand/rubber wheel apparatus, 1996 Annual Book of ASTM Standards, Volume 03. 02, ASTM.

DOI: 10.2118/170520-ms

[5] M.G. Gee, A.J. Gant and W.P. Byrne, An NPL Rotating Wheel Abrasion Test, NPL Measurement Note, CMMT(MN)30, November (1998).

[6] I. Konyashin, B. Ries, D. Hlawatschek, Y. Zhuk, A. Mazilkin, B. Straumal, F. Dorn, D. Park Wear-Resistance and Hardness: Are They Directly Related for Nanostructured Hard Materials? Int. Journal of Refractory Metals and Hard Materials (2014).

DOI: 10.1016/j.ijrmhm.2014.06.017
