Comparative Study of the VARTM, VAP and MTI Vacuum Infusion Processes

Abstract:

The vacuum infusion process is widely used for the manufacture of fiber reinforced polymer composites. Current research concentrates on the comparison of three alternative methods. The aim is to determine if the Membrane Tube Infusion (MTI) and the Vacuum Assisted Process (VAP) that both use membrane fabric are able to produce higher quality laminate compared to the more established Vacuum Assisted Resin Transfer Moulding (VARTM). The laminate quality was evaluated by the void content, fiber volume fraction and mechanical properties. In addition, the thickness was measured in different segments of the laminate in order to determine if the thickness changes along the laminate. The MTI and VAP process did not give a significant improvement of the measured properties, on the contrary, the VARTM outran the aforementioned in many aspects.

• Periodical: Key Engineering Materials (Volume 674)
• Pages: 71-76
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.674.71
• Online since: January 2016
• Authors: Aare Aruniit*, Hendrik Herranen, Kristen Miller
• Keywords: CFRP, Fiber Reinforced Plastic, GFRP, MTI Hose, Polymer Composites, SCRIMP, Semi-Permeable Membrane Fabric, Vacuum Infusion Process, VAP, VARTM

References

[1] W.H. Seemann, U.S. Patent 5, 052, 906. (1991).

[2] S. T. Peters, Handbook of Composites, 2nd ed., Chapman & Hall, London, (1998).

[3] P. Schulze, D. Heider, Variability in aerospace VARTM, The 8th International Conference on Flow Processes in Composite Materials (FPCM8). (2006) 85–88.

[4] W. Li, Process and Performance Evaluation of the Vacuum-Assisted Process, Journal of Composite Materials. 38 (2004) 1803–1814.

[5] J. Yang, J. Xiao, J. Zeng, D. Jiang, C. Peng, Compaction behavior and part thickness variation in vacuum infusion molding process, Applied Composite Materials. 19 (2012) 443–458.

DOI: 10.1007/s10443-011-9217-8

[6] J.C. Waldrop, W.R. Burkett, C.J. Sesti, B. Harshman, A.F. Tegeler, and W.P. Weinman, US 7, 413, 694 B2. (2008).

[7] S.C. Amouroux, D. Heider, J.W. Gillespie, Characterization of membranes used in pressure driven composite processing, Composites Part A. 41 (2010) 207–214.

DOI: 10.1016/j.compositesa.2009.10.014

[8] J. P. Pascault and R. J. J. Williams, Epoxy Polymers, Wiley, (2009).

[9] J. Schildgen, MTI Process, German Advanced Composites Inc., Miami, (2015).

[10] M.W. Nielsen, J.H. Hattel, T.L. Andersen, K. Branner, P.H. Nielsen, P.M. Group, R. Denmark, A 1D coupled curing and visco-mechanical void growth model of thick thermosetting composite laminates, 18th International Conference on Composite Materials. (2011).

[11] L. A. Carlsson, D. F. Adams, and R. B. Pipes, Experimental Characterization of Advanced Composite Materials, Fourth Edition, Taylor & Francis, (2014).

[12] T.A. Cender, J.J. Gangloff Jr., P. Simacek, S.G. Advani, Void Reduction During Out-of-Autoclave Thermoset Prepreg Composite Processing, SAMPE 2014 Proceedings. (2014).

[13] A.D. Kelkar, J.S. Tate, P. Chaphalkar, Performance evaluation of VARTM manufactured textile composites for the aerospace and defense applications, Materials Science and Engineering B: Solid-State Materials for Advanced Technology. 132 (2006).

DOI: 10.1016/j.mseb.2006.02.034

[14] L.R. Holmes, J.P. Wolbert, J.M. Gardner, A Method for Out-of-autoclave Fabrication of High Fiber Volume Fraction Fiber Reinforced Polymer Composites, Army Research Laboratory. (2012).

DOI: 10.21236/ada571902

[15] S.R. Ghiorse, Effect of void content on the mechanical properties of carbon/epoxy laminates, SAMPE quarterly. 24 (1993) 54–59.

[16] H. Zhu, B. Wu, D. Li, D. Zhang, Y. Chen, Influence of Voids on the Tensile Performance of Carbon/epoxy Fabric Laminates, Journal of Materials Science and Technology. 27 (2011) 69–73.

DOI: 10.1016/s1005-0302(11)60028-5
