Research on Cutting Force of Corner Milling of Inclined Plane

Abstract:

When milling corners in high speed, it will lead the mutation of cutting force that affects the processing quality and processing efficiency. In order to study the influence of milling parameters on milling force in the corner. Firstly, an orthogonal experimental of corner is designed to study the influence of various cutting parameters on cutting force. Axial cutting depth, radial depth, spindle speed and feed speed, as the major influence factors, impact on cutting force in corner milling. Then, a cutting force model of corner is established based on a method of orthogonal experiment linear regression. The significance test of regression equation and regression coefficient shows that cutting force model is accurate. The cutting force model is used to predict the cutting force, and then select the appropriate cutting parameters.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 856-862
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.856
• Online since: May 2016
• Authors: Shi Xiong Wu*, Bin Li, Wei Ma
• Keywords: Corner, Cutting Force, High-Speed Milling, Inclined Plane, Linear Regression Analysis

References

[1] V Pateloup, E Duc, P Ray. Corner optimization for pocket machining[J]. International Journal of Machine Tools & Manufacture . 2004, 44(12): 1343～1353.

DOI: 10.1016/j.ijmachtools.2004.04.011

[2] R C Dewes, D K Aspinwall. A review of ultrahigh speed milling of hardened steels[J], Mater. Process Technol. 1997(69): 1–17.

[3] WU Shixiong, LI Kaizhu, WANG Lei. Corner Tool Path Optimization in High Speed Milling [J]. Machinery Design & Manufacture . 2012, (8): 245-247.

[4] Kishawy HA , Elbestawi MA. Effects of process parameters on material side flow during hard turning[J]. International Journal of Machine Tools & Manufacture, 1999, 39: 17–30.

DOI: 10.1016/s0890-6955(98)00084-4

[5] Won-Soo Yun, Dong-Woo Cho. Accurate 3-D cutting force prediction using cutting condition independent coefficients in end milling[J], International Journal of Machine Tools & Manufacture, 2001, 41: 463–478.

DOI: 10.1016/s0890-6955(00)00097-3

[6] Wu Qiong, Zhang Yidu, Zhang Hongwei. Corner-milling of Thin Walled Cavities on Aeronautical Components[J]. Chinese Journal of Aeronautics , 2009, 22 (6): 677-684.

DOI: 10.1016/s1000-9361(08)60158-2

[7] Douglas C, Montgomery. Design and analysis of experiment[M]. New York: Wiley, (1997).

[8] Douglas C, Montgomery. Elizabeth A Peck G. Introduction to Linear Regression Analysis[M]. New York: Wiley, (2006).
