The PACE-1450 Test Campaign - Leakage Behaviour of a Pre-Stressed Concrete Containment Wall Segment

Abstract:

Investigating nuclear power plant containments under accidental conditions obviously leads to the question of possible leakage through cracks of the pre-stressed concrete containment. In the last decades a number of civil engineering R&D programs dedicated to theoretical and experimental analyses have been performed. For the PACE-1450 experiment a leakage testing facility for pre-stressed curved specimen has been built in the laboratory of the Materials Testing and Research Institute (MPA Karlsruhe) at the Karlsruhe Institute of Technology (KIT). The test campaign has now been successfully finished with the evaluation of gained results still ongoing. The first half of the campaign was mainly dedicated to the cracking of the realistically reinforced specimen while the second half was focussing on the leakage behaviour of the cracked specimen. In the tests cold air, heated air and air-steam mixtures were used.

• Periodical: Key Engineering Materials (Volume 711)
• Pages: 863-870
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.711.863
• Online since: September 2016
• Authors: Nico Herrmann*, Harald S. Müller, Christoph Niklasch, Sylvie Michel-Ponnelle, Benoît Masson
• Keywords: Aging, Containment, Cracks, Leakage, Pre-Stressing, Reactor Safety

References

[1] Le Pape, Y., Courtois, A., Ghavamian, S.: Nuclear power plant concrete containment: monitoring and modelling the aging mechanisms, Proceedings of the International Symposium: Contribution of materials investigations to improve the safety and performance of LWRs, Vol. 2, 1145-1155, Fontevraud 6, France, (2006).

[2] Niklasch, C., Herrmann, N.: Nonlinear fluid–structure interaction calculation of the leakage behaviour of cracked concrete walls, Nuclear Engineering and Design, Volume 239, September, Issue 9, pp.1628-1640, (2009).

DOI: 10.1016/j.nucengdes.2008.09.001

[3] Herrmann, N., Müller, H. S., Niklasch, C., Michel-Ponnelle, S., Le Pape, Y., Bento, C.: PACE-1450 – The Crack and Leakage Behaviour of a Pre-stressed Concrete considering the Pre-stressing Loss due to Aging,; 22th International Conference on Structural Mechanics in Reactor Technology; SMiRT22, August 18-23, San Francisco, USA, (2013).

DOI: 10.4028/www.scientific.net/kem.711.863

[4] Herrmann, N., Müller, H. S., Niklasch, C., Michel-Ponnelle, S., Bento, C., Masson, B.: The PACE-1450 experiment – Crack and leakage behaviour of a pre-stressed concrete containment wall considering the aging, Contribution of Materials Investigations and Operating Experience to LWRs, Safety, Performance and Reliability, Fontevraud 8, Avignon, France, (2014).

DOI: 10.4028/www.scientific.net/kem.711.863

[5] Herrmann, N.; Niklasch, C.; Kiefer, D.; Gerlach, L.; Le Pape, Y.; Fortier, S.: PACE-1450 – An experimental Test Setup for the Investigation of the Crack Behaviour of Pre stressed Concrete Containment Walls; Proceedings of the 16th International Conference on Nuclear Engineering; ICONE16, May 11-15, Orlando, FL, USA, (2008).

DOI: 10.1115/icone16-48029
