Experiment and FE Analysis of Compression of Thick Ring Filled with Oil

Abstract:

Reducing automobile weight has been necessarily accelerated to save energy and improve drivability. Accordingly, use of high strength steel and hollow sections help in weight reduction. In this study, the effect of trapped oil has been investigated to improve the metal flow in upsetting of a hollow workpiece using no mandrel. It was found that the ideal deformation without friction between the dies and the workpiece was nearly achieved when a low and thick ring with trapped oil was upset. The inner diameter of the oil-filled ring was expanded more than that of the benchmark ring. The effect of the expansion of the ring and the reduction of the friction proved helpful in trial forming of a gear preform.

• Periodical: Key Engineering Materials (Volume 767)
• Pages: 141-148
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.767.141
• Online since: April 2018
• Authors: Yoshiki Tatematsu, Mitsuka Morimoto, Kazuhiko Kitamura
• Keywords: Cold Forging, Hydrostatic Pressure, Lubrication

References

[1] M. Kunogi, A Study on Plastic Deformation of Hollow Cylinder Being Subjected to Axial Load, J. Scientific Research Inst., Japan, No. 30, vol. 2 (1954) pp.63-91. (In Japanese).

[2] H. Kudo, An Analysis of Plastic Compressive Deformation of Lamella Between Rough Plates by Energy Method, Proceeding of the 5th Japan National Congress for App. Mech. 1955, pp.75-78.

[3] Precise Measurement and Prediction of Bulk-Modulus Values for Fluids and Lubricants, Transaction of ASME, Ser. D, Journal of Basic Engineering, No. 86, vol. 3 (1964), pp.469-474.

DOI: 10.1115/1.3653146

[4] M.Shinohara, Friction and Lubrication in Upsetting of Bar under High Environmental Pressures, Journal of JSTP, 19-214 (1978), 926-933. (In Japanese).
