Experimental Investigation on Masonry with Textile Reinforcement in Thin Bed Joints

Abstract:

The application of textile reinforcement can help to increase the load-bearing capacity of masonry building components, especially those subjected to lateral loads caused by wind, earth pressure or earthquake. The reinforcement can be applied externally or be integrated in the bed joint. The key part of an ongoing research project is to investigate the bonding and load-bearing behavior of masonry building components reinforced with textile in thin bed joints with the aim to develop reinforcing elements. With these reinforcing elements for bed joints the construction of basements and higher buildings will be more attractive with masonry. In the first part of the project, the relevant material and bond properties of preselected materials were determined, and a suitable textile was selected. In the second part, four-point bending tests on unreinforced and reinforced masonry wall specimens were carried out in order to investigate the effectiveness of bed joint textile reinforcement to increase the masonry flexural tensile strength. In the third part, a proposal for the design of prototypical reinforcing elements will be worked out. This paper deals with the two first parts of the research project.

• Periodical: Key Engineering Materials (Volume 817)
• Pages: 404-411
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.817.404
• Online since: August 2019
• Authors: Dorothea Saenger*, Michael Raupach
• Keywords: Carbon Textile, Hollow Clay Units, Reinforced Masonry, Textile Reinforcement, Thin Bed Masonry, Thin Layer Mortar

References

[1] Brameshuber, W.; Saenger D.; Winkels, B.: Recent Developments in Masonry Construction. Mauerwerk – European Journal of Masonry 18 (2014), no. 3/4, pp.151-163 ISSN 1432-3427.

DOI: 10.1002/dama.201400624

[2] Brameshuber, W.; Graubohm, M.; Saenger, D.: Prefabricated Thin Layers of Mortar for Masonry. In: Proceedings of the 16th International Brick and Block Masonry Conference. Trends, Innovations and Challenges, Padova, Italy, 26-30 June 2016, pp.2201-2206 ISBN 978-1-138-02999-6.

DOI: 10.1201/b21889-272

[3] Saenger, D.; Raupach, M.: Experimental Study on the Performance of Textile Reinforced Masonry under Flexural Load. Farmington Hill: American Concrete Institute, SP-324: Composites with Inorganic Matrix for Repair of Concrete and Masonry Structures (2018), pp.10-14 ISBN 978-1-641-95005-3.

DOI: 10.14359/51702362

[4] Saenger, D.; Raupach, M.: Experimental Study on Textile Reinforced Masonry Walls Subjected to Lateral Loading. In: Proceedings of the 13th Canadian Masonry Symposium, Halifax, Canada, 4-7 June (2017).

[5] DIN EN 998-2 Specification for mortar for masonry - Part 2: Masonry mortar (2017).

[6] DIN EN 1015-10 Methods of test for mortar for masonry - Part 10: Determination of dry bulk density of hardened mortar (2007).

DOI: 10.3403/01905430u

[7] DIN EN 1015-11 Methods of test for mortar for masonry - Part 11: Determination of flexural and compressive strength of hardened mortar (2018).

DOI: 10.3403/01905442u

[8] DIN EN 772-13 Methods of test for masonry units - Part 13: Determination of net and gross dry density of masonry units (except for natural stone) (2000).

DOI: 10.3403/01784881

[9] DIN EN 772-1 Methods of test for masonry units - Part 1: Determination of compressive strength (2016).

[10] Brameshuber, W.: RILEM TC 232-TDT: Recommendation of RILEM TC 232-TDT: Test Methods and Design of Textile Reinforced Concrete. Uniaxial Tensile Test: Test Method to Determine the Load Bearing Behavior of Tensile Specimens Made of Textile Reinforced Concrete. Materials and Structures, RILEM 49 (2016), no. 12, pp.4923-4927.

DOI: 10.1617/s11527-016-0839-z

[11] Saenger, D.; Brameshuber, W.: Bond Behaviour between Textile and Mortar for Masonry Strengthening. In: Proceedings of the 16th International Brick and Block Masonry Conference. Trends, Innovations and Challenges, Padova, Italy, 26-30 June 2016, pp.425-431 ISBN 978-1-138-02999-6.

DOI: 10.1201/b21889-51

[12] DIN EN 1052-2 Methods of test for masonry - Part 2: Determination of flexural strength (2018).
