Experimental of Inverted-T Shape Reinforced Concrete Wall Subjected to Blast Load

Abstract:

Reinforced concrete (RC) widely used as the construction material for the main structural element for many significant structures such as bridge and building because of its relatively high strength and economical. However, there still lacks research published regarding the appropriate reinforcement steel arrangement in a complete RC structure subjected to blast load. Most of the published experimental works focused on the small rectangular or square RC panel. From the record search, the approved design by professional engineers, when RC wall subjected to the possibility of blast load, both RC wall details either retaining wall or shear wall implemented. Therefore, the full-scale blast experiment is vital to appraise the appropriate steel reinforcement arrangement in the RC wall. The blast experiment indicated, with different steel reinforcement arrangement in the RC wall, the better blast resistance with the number of cracks on the RC wall is significantly less from one another for the wall with the arrangement of horizontal flexural reinforcement tied-outside the vertical flexural reinforcement and the hooked-in direction of vertical flexural steel reinforcement into the wall base.

• Periodical: Key Engineering Materials (Volume 879)
• Pages: 254-262
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.879.254
• Online since: March 2021
• Authors: Mazlan Abu Seman*, Sharifah Maszura Syed Mohsin, Ahmad Mujahid Ahmad Zaidi, Md Fuad Shah Koslan, Zainorizuan Mohd Jaini
• Keywords: Blast, Reinforced Concrete, Structure, Wall

References

[1] N. Demetris, K. Antonis, S. Pericles, P. Micheal, Experimental field investigation of impact and blast load resistance of ultra-high performance fibre reinforce cementious composites (UHPFRCCs), Construction and Building Materials. 95 (2015) 566-574.

DOI: 10.1016/j.conbuildmat.2015.07.141

[2] R. Castedo, P. Segarra, A. Alanon, L.M. Lopez, A.P. Santos, J.A. Sanchidrian, Air blast resistance of full-scale slabs with different compositions: Numerical modeling and field validation, International Journal of Impact Engineering, 86 (2015) 1419-1426.

DOI: 10.1016/j.ijimpeng.2015.08.004

[3] G. Thiagarajan, A. V. Kadambi, S. Robert, C. F. Johnson, Experimental and finite element analysis of doubly reinforced concrete wall subjected to blast loads, International Journal of Impact Engineering, 75 (2015) 162–173.

DOI: 10.1016/j.ijimpeng.2014.07.018

[4] U.J. Alengaram, N.H.W. Mohottige, C. Wu, M.Z. Jumaat, Y.S. Poh, Z. Wang, Response of oil palm shell concrete subjected to quasi-static and blast loads, Construction and Building Materials, 116 (2016) 391-402.

DOI: 10.1016/j.conbuildmat.2016.04.103

[5] J. Li, C. Wu, H. Hao, Y. Su, X. Z Li, A study of concrete slabs with steel wire mesh reinforcement under close-in explosive load, International Journal of Impact Engineering. 110 (2017) 242-254.

DOI: 10.1016/j.ijimpeng.2017.01.016

[6] L. Jian, W. Chengqing, L. Chunguang, D. Wenxue, S. Yu, L. Jun, C. Ning, Z. Fan, D. Lan, M. Qingfei, P. Jiabao, Blast testing of high performance geopolymer composite walls reinforced with steel wire mesh and aluminium foam, Construction and Building Materials, 197 (2019) 533-547.

DOI: 10.1016/j.conbuildmat.2018.11.207

[7] Y. Fei, F. Wanhui, J. Lin, Y. Bing, C. De, Experimental and numerical study of rubber concrete slabs steel reinforcement under close-in blast loading, Construction and Building Materials, 198 (2019) 423-436.

DOI: 10.1016/j.conbuildmat.2018.11.248

[8] D. Yan, G. Chen, J. Baird, H. Yin, M. Koenigstein, Blast test of full-Size wall barriers reinforced with enamel-coated steel rebar, Proceedings of the Structure Congress, (2011) 1538-1551.

DOI: 10.1061/41171(401)134

[9] H. Radek, F. Marek, F. Josef, Influence of barrier material and barrier shape on blast mitigation, Construction and Building Material, 120 (2016) 54-64.

DOI: 10.1016/j.conbuildmat.2016.05.078

[10] L. S. Chao, L. Dan, Y. Bo, Experimental study and numerical simulation on damage assessment of reinforced concrete beams, International Journal of Impact Engineering, 132 (2019).

[11] A. Dua, A. Braimah, M. Kumar, Experimental and numerical investigation of rectangular reinforced concrete T columns under contact explosion effects, Engineering Structure, 205 (2020).

DOI: 10.1016/j.engstruct.2019.109891

[12] TNB, Contract No. TNB 586/2005 Supply, erect & commissioning of 132 kV and 11 kV switchgear and ancillary equipment complete with associated civil works at transmission main intake substation in eastern region, (2005).

[13] TNB, Contract No. TNB 342/2006 Supply, erect & commissioning of 132 kV and 33 kV switchgear and ancillary equipment and associated civil works for PMU Teluk Kalong, (2006).

[14] L.A. Wyllie, R.W. Laplante, The designer's responsibility for rebar design, Concrete Reinforcing Steel Institute, 1 (2003) 1–16.
