Selective Laser Melting of Ti-6Al-4V Lattices: Case Study on a Spinal Cage Prosthesis

Abstract:

Biomedical prostheses are artificial devices suitable for the replacement of missing or inefficient parts of the body, implanted to reduce the anatomical or functional deficiency, and sometimes also applied for aesthetic purposes. Despite this type of medical devices represents today a very innovative sector from the medical and engineering point of view, some issues, inherent to the interaction between human body and the external hosts must be considered. It is important that the weight and porosity of the prosthesis respect the patient’s physiological equilibrium which permit an appropriate osseointegration where needed. A typical solution is a lattice structure, which can be manufactured by Additive Manufacturing techniques which, as known, permit to build complex geometries in comparison with other processing routes. Lattice structure are typically characterized by both stiffness and strength significantly lower than the full part of the structure. Generally, for this reason, the lattices are applied to the low-stress areas, leaving a portion of solid sufficient to transmit the loads involved, or in such a way to guarantee the desired flexibility of the part-itself. During the design of lattices some limitations regarding their printability must be considered, such as the minimum printable dimension and the necessary support parts. A Design of Experiment analysis was conducted to identify the optimal parameters to manufacture a spinal cage with negligible porosity via laser powder bed fusion using Ti6Al4V alloy.

• Periodical: Key Engineering Materials (Volume 926)
• Pages: 147-158
• DOI: https://doi.org/10.4028/p-g7ip54
• Online since: July 2022
• Authors: Francesco Cantaboni*, Paola Ginestra, Marialaura Tocci, Elisabetta Ceretti, Giulia De Sio, Xue Cao, Luke N. Carter, Victor M. Villapún, Morgan Lowther, Sophie Louth, Sophie C. Cox
• Keywords: Case Study, Lattice Structure, Porosity, Powder Bed Fusion

References

[1] T. Majumdar, N. Eisenstein, J. E. Frith, S. C. Cox, and N. Birbilis, Additive Manufacturing of Titanium Alloys for Orthopedic Applications: A Materials Science Viewpoint,, Adv. Eng. Mater., vol. 20, no. 9, 2018,.

DOI: 10.1002/adem.201800172

[2] G. Allegri, A. Colpani, P. S. Ginestra, and A. Attanasio, An experimental study on micro-milling of a medical grade Co-Cr-Mo alloy produced by selective laser melting,, Materials (Basel)., vol. 12, no. 13, 2019,.

DOI: 10.3390/ma12132208

[3] M. Vignesh et al., Development of Biomedical Implants through Additive Manufacturing: A Review,, J. Mater. Eng. Perform., vol. 30, no. 7, p.4735–4744, 2021,.

DOI: 10.1007/s11665-021-05578-7

[4] H. Salem, L. N. Carter, M. M. Attallah, and H. G. Salem, Influence of processing parameters on internal porosity and types of defects formed in Ti6Al4V lattice structure fabricated by selective laser melting,, Mater. Sci. Eng. A, vol. 767, no. May, p.138387, 2019,.

DOI: 10.1016/j.msea.2019.138387

[5] S. K. Gupta et al., Enhanced biomechanical performance of additively manufactured Ti-6Al-4V bone plates,, J. Mech. Behav. Biomed. Mater., vol. 119, no. March, p.104552, 2021,.

DOI: 10.1016/j.jmbbm.2021.104552

[6] P. Ginestra et al., Post processing of 3D printed metal scaffolds: A preliminary study of antimicrobial efficiency,, Procedia Manuf., vol. 47, no. 2019, p.1106–1112, 2020,.

DOI: 10.1016/j.promfg.2020.04.126

[7] L. Riva, P. S. Ginestra, and E. Ceretti, Mechanical characterization and properties of laser-based powder bed–fused lattice structures: a review,, Int. J. Adv. Manuf. Technol., vol. 113, no. 3–4, p.649–671, 2021,.

DOI: 10.1007/s00170-021-06631-4

[8] P. Ginestra et al., Surface ace finish of A Additi dditiv vel ely y Manuf Manufactur actured ed Metals : biofilm f formation ormation and cellular attachment 1 Intr Introduction oduction 2 Manuf Manufacturing acturing and post pr processing ocessing treatment,, vol. 13, p.1–12, (2021).

[9] T. Majumdar, T. Bazin, E. M. C. Ribeiro, J. E. Frith, and N. Birbilis, Understanding the effects of PBF process parameter interplay on Ti-6Al-4V surface properties,, PLoS One, vol. 14, no. 8, p.1–24, 2019,.

DOI: 10.1371/journal.pone.0221198

[10] M. Nakatani, H. Masuo, Y. Tanaka, and Y. Murakami, Effect of Surface Roughness on Fatigue Strength of Ti-6Al-4V Alloy Manufactured by Additive Manufacturing,, Procedia Struct. Integr., vol. 19, p.294–301, 2019,.

DOI: 10.1016/j.prostr.2019.12.032
