Material Parameters Sensitivity on Springback Modelling of Simple Bending Process

Abstract:

Springback is one of the major defects that continuously concerns the sheet metal experts’ community. It is has long been known that the sheet thickness, the bending angle and the yield stress of the material primarily affect the angle change after the tools’ release. Besides, the consideration of the kinematic hardening (KH) model has powerful influence on the modelling results, too. In this study, we overviewed several possible factors on the springback with finite element modeling of a simple V-die bending operation, highlighting the effect of the material variables on the final shape. AutoForm® R7 software and the built-in theory of kinematic hardening were used for the material characterization, coupled with the Hockett-Sherby isotropic hardening rule as well as the Yld89 yield criterion. The material data for modeling kinematic hardening behavior were obtained by cyclic tension-compression tests, whilst the isotropic hardening and the yield surface parameters were acquired by simple uniaxial tension tests. The simulation results were compared to the experimental springback observations obtained by a CNC bending machine, without using springback compensation. A detailed parametric study was also carried out to highlight the level of criticality of the applied material variables on the final angle change.

• Periodical: Key Engineering Materials (Volume 926)
• Pages: 992-999
• DOI: https://doi.org/10.4028/p-41cjie
• Online since: July 2022
• Authors: Gábor J. Béres*, Zsolt Lukács, Miklós Tisza
• Keywords: Kinematic Hardening, Parametric Study, Springback Modeling

References

[1] G.J. Béres, F. Végvári, J. Danyi, Some Formability Aspects of High Strength Steels and of Consisting Tailor Welded Blanks, Acta Materialia Transylvanica 4/1 (2021) 18–23.

DOI: 10.33924/amt-2021-01-03

[2] Z. Marciniak, J.L. Duncan, S.J. Hu, Mechanics of Sheet Metal Forming. Butterworth-Heinemann, Oxford, (2002).

[3] K. Lange, Handbook of Metal Forming. SME, Dearborn:Michigan, (1985).

[4] R. Pearce, Sheet metal forming, Adam Hilger Series on new manufacturing processes and materials, IOP Publising Ltd, (1991).

[5] Metals Handbook Vol. 4. Forming. 8th ed., American Society for Metals, Ohio, Metals Park, (1969).

[6] J.L. Chaboche, Constitutive equations for cyclic plasticity and cyclic viscoplasticity, International Journal of Plasticity 5 (1989) 247–302.

DOI: 10.1016/0749-6419(89)90015-6

[7] F. Yoshida, T. Uemori, A model of large-strain cyclic plasticity describing the Bauschinger effect and workhardening stagnation, International Journal of Plasticity 18 (2002) 661–686.

DOI: 10.1016/s0749-6419(01)00050-x

[8] F. Yoshida, T. Uemori, A model of large-strain cyclic plasticity and its application to springback simulation, International Journal of Mechanical Sciences 45 (2003) 1687–1702.

DOI: 10.1016/j.ijmecsci.2003.10.013

[9] S. Keeler, M. Kimchi, Advanced High-Strength Steels Application Guidelines Version 6.0. 3S-Superior Stamping Solutions, LLC., WorldAutoSteel, (2017).

[10] R. Kuziak, R. Kawalla, S. Waengler, Advanced high strength steels for automotive industry. Archives of Civil and Mechanical Engineering, VIII (2008) 103-117.

DOI: 10.1016/s1644-9665(12)60197-6

[11] M. Tisza, Zs. Lukács, Formability investigations of high strength dual phase steels, IDDRG 2015, pp.320-337.

[12] J.E. Hockett, O.D. Sherby, J. Mech. Phys. Solids, 23 (1975) 87-98.

[13] F. Barlat, J. Lian, Plastic behavior and stretchability of sheet metals. Part I: A yield function for orthotropic sheets under plane stress conditions. International Journal of Plasticity, Vol. 5 (1989) 51-66.

DOI: 10.1016/0749-6419(89)90019-3

[14] R. Hill, A theory of the yielding and plastic flow of anisotropic metals. The hydrodynamics of non-Newtonian fluids, I (1947) 281-297.

[15] W. Kubli, A. Krasovskyy, M. Sester, Modeling of reverse loading effects including workhardening stagnation and early re-plastification, Int J Mater Form Suppl 1 (2008) 145–148.

DOI: 10.1007/s12289-008-0012-5
