The Ability of NiFe₂O₄ Samples to Reduce Electromagnetic Wave Pollution in the Frequency Range of 2-18 Ghz

Abstract:

Rapid technological developments have the impact of increasing electromagnetic wave pollution. To reduce this pollution, nickel ferrite (NiFe₂O₄) nanoparticles are made by using mechanical alloying method with high energy milling in a wet state. X-ray diffractometer was used to characterize the crystal structure and the formed phase; scanning electron microscopy was used to characterize surface morphology; and for magnetization, a vibrating sample of magnetometer was used. Meanwhile, the capability to absorb electromagnetic waves in the 2-18 GHz interval was using a vector network analyzer. NiFe₂O₄ nanoparticles have a cubic structure, space group Fd-3m, and a crystal size of 127 nm. The shape of the particles resembles a block and is spherical, measuring about 250-300 nm. At room temperature, NiFe₂O₄ nanoparticles are soft magnetic materials with a magnetic saturation (Ms) of 41.61 emu/g and a coercivity (Hc) of 0.24 kOe. The ability to absorb microwaves, is expressed by reflection loss (RL) ~ -25.81 dB at a frequency (f) 5.16 GHz with a bandwidth (BW) 1.62 GHz, while RL ~ - 18.64 dB at f = 10, 98 GHz with BW = 1.42 GHz.

• Periodical: Key Engineering Materials (Volume 940)
• Pages: 39-46
• DOI: https://doi.org/10.4028/p-9r8oui
• Online since: January 2023
• Authors: Yohanes Edi Gunanto*, Henni Sitompul, Maya Puspitasari Izaak, Yosef Sarwanto, Wisnu Ari Adi
• Keywords: Absorber, Electromagnetics, Milling, Nickel-Ferrite, Pollution

References

[1] Y. Huang, M. Chen, A. Xie, Y. Wang, and X. Xu, Recent Advances in Design and Fabrication of Nanocomposites for Electromagnetic Wave Shielding and Absorbing. Materials,14, 4148 (2021). https:// doi.org/10.3390/ma14154148.

DOI: 10.3390/ma14154148

[2] S. Solgi, M. S. S. Dorraji, S. F. Hosseini, M. H. Rasoulifard, I. Hajimiri, and A. A.-Ghadim, Improvement of microwave absorption properties of polyester coatings using NiFe2O4, X-doped g-C3N4 (X = S, P, and O), and MTiO3 (M = Fe, Mg, and Zn) nanofillers. Sci Rep 11, 19339 (2021). https://doi.org/10.1038/s41598-021-98666-6.

DOI: 10.1038/s41598-021-98666-6

[3] D. Mandal, A. Gorai, and K. Mandal, Electromagnetic wave trapping in NiFe2O4 nano-hollow spheres: An efficient microwave absorber, Journal of Magnetism and Magnetic Materials, Volume 485 (2019) 43-48. https://doi.org/10.1016/j.jmmm.2019.04.033.

DOI: 10.1016/j.jmmm.2019.04.033

[4] J. Xie, H. Jiang, J. Li, F. Huang, A. Zaman, X. Chen, D. Gao, Y. Guo, D. Hui, and Z. Zhou, Improved impedance matching by multi- componential metal-hybridized rGO toward high performance of microwave absorption, Nanotechnology Reviews, 10 (2021) 1-9. https://doi.org/10.1515/ntrev-2021-0001.

DOI: 10.1515/ntrev-2021-0001

[5] I. R.Ibrahim, K. A. Matori, I. Ismail, Z. Awang, S.N. A. Rusly, R. Nazlan, F. M.Idris, M. M. M. Zulkimi, N. H. Abdullah, M. S. Musta, F. N. Shafieee, and M. Ertugrul, A Study on Microwave Absorption Properties of Carbon Black and Ni0.6Zn0.4Fe2O4 Nanocomposites by Tuning the Matching-Absorbing Layer Structures, Scientific Reports, 10 3135 (2020). https://doi.org/10.1038/s41598-020-60107-1.

DOI: 10.1038/s41598-020-60107-1

[6] S. Prabhu, M. Geerthana, S. Sohila, G. M. Bhalerao, S. Harish, M. Navaneethan, Y. Hayakawa, and R. Ramesh, Preparation of Cr3+-Substituted NiFe2O4 Nanoparticles and Its Microwave Absorption Properties. J Supercond Nov Magn 32 (2019) 1423-1429. https://doi.org/10.1007/s10948-018-4835-0.

DOI: 10.1007/s10948-018-4835-0

[7] F. Wang, X. Wang, J. Zhu, H. Yang, X. Kong, and X. Liu, Lightweight NiFe2O4 with controllable 3D network structure and enhanced microwave absorbing properties, Scientific Reports, 6:37892 (2016).

DOI: 10.1038/srep37892

[8] Y. Qiao, J. Xiao, Q. Jia, L. Lu, and H. Fan, Preparation and microwave absorption properties of ZnFe2O4/polyaniline/ graphene oxide composite, Results in Physics, Volume 13, 102221 (2019). https://doi.org/10.1016/j.rinp.2019.102221.

DOI: 10.1016/j.rinp.2019.102221

[9] E. Sukirman, Y. Sarwanto, S. Ahda, Y. Taryana, and S. Purwanto, Detailed Multiband Electromagnetic Wave Absorption Study on Nanocrystalline (1-x)NiFe2O4/(x)BaTiO3 Composites. Newest Updates in Physical Science Research Vol. 2 (2021) 35-48. https://doi.org/10.9734/bpi/nupsr/v2/7215D.

DOI: 10.9734/bpi/nupsr/v2/7215d

[10] P. Yin, L. Zhang, J. Wang, X. Feng, L. Zhao, H. Rao, Y. Wang, and J. Dai, Preparation of SiO2-MnFe2O4 Composites via One-Pot Hydrothermal Synthesis Method and Microwave Absorption Investigation in S-Band, Molecules, 24, 2605 (2019).

DOI: 10.3390/molecules24142605

[11] T. Dippong, E. A. Levei, I. G. Deac, E. Neag, and O. Cadar, Influence of Cu2+, Ni2+, and Zn2+ Ions Doping on the Structure, Morphology, and Magnetic Properties of Co-Ferrite Embedded in SiO2 Matrix Obtained by an Innovative Sol-Gel Route, Nanomaterials, 10, 580 (2020).

DOI: 10.3390/nano10030580

[12] Y. E. Gunanto, M. P. Izaak, S. S. Silaban, and W. A. Adi, Effect of milling time on microwave absorption ability on barium-hexaferrite nanoparticles, J. Phys.: Conf. Ser. 1011 012058 (2018). http://dx.doi.org/10.1088/1742-6596/1011/1/012058.

DOI: 10.1088/1742-6596/1011/1/012058

[13] R. S. Yadav, I. Kurǐtka, J. Vilcakova, M. Machovsky, D. Skoda, P. Urbańek, M. Masar,̌ M. Jurcǎ, M. Urbańek, L. Kalina, and J. Havlica, NiFe2O4 Nanoparticles Synthesized by Dextrin from Corn-Mediated Sol−Gel Combustion Method and Its Polypropylene Nanocomposites Engineered with Reduced Graphene Oxide for the Reduction of Electromagnetic Pollution, ACS Omega, 4 (2019) 22069-22081.

DOI: 10.1021/acsomega.9b03191

[14] Y. E. Gunanto, H. Sitompul, M. P. Izaak, E. Jobiliong, Y. Sarwanto, and W. A. Adi, The effect of Zn-dopant on the anisotropy constant and reflection loss of the Ba0.6Sr0.4Fe10-xZnxMnTiO19 (x = 0.1, 0.3, and 0.5), Journal of Magnetism and Magnetic Materials 553, 169172 (2022). https://doi.org/10.1016/j.jmmm.2022.169172.

DOI: 10.1016/j.jmmm.2022.169172

[15] Henrik Lyder Andersen, Matilde Saura-Múzquiz, Cecilia Granados-Miralles, Emmanuel Can´evet, Nina Lock, Mogens Christensen, Crystalline and magnetic structure-property relationship in spinel ferrite nanoparticles, Nanoscale 10 (31) (2018) 14902–14914, https://doi.org/10.1039/C8NR01534A.

DOI: 10.1039/c8nr01534a

[16] G. Dixit, J.P. Singh, C.L. Chen, C.L. Dong, R.C. Srivastava, H.M. Agrawal, W. F. Pong, K. Asokan, Study of structural, morphological and electrical properties of Ce doped NiFe2O4 nanoparticles and their electronic structure investigation, J. Alloy. Compd. 581 (2013) 178–185, https://doi.org/10.1016/j.jallcom.2013.07.047.

DOI: 10.1016/j.jallcom.2013.07.047

[17] L.Y. Matzui, A.V. Trukhanov, O.S. Yakovenko, L.L. Vovchenko, V.V. Zagorodnii, V. V. Oliynyk, M.O. Borovoy, E.L. Trukhanova, K.A. Astapovich, D.V. Karpinsky, S. V. Trukhanov, Functional magnetic composites based on hexaferrites: correlation of the composition, magnetic and high-frequency properties, Nanomaterials 9 (2019) 1–17, https://doi.org/10.3390/nano9121720.

DOI: 10.3390/nano9121720

[18] K. Ugendar, V. Hari Babu, V. Raghavendra Reddy, G. Markaneyulu, Cationic ordering and magnetic properties of rare-earth doped NiFe2O4 probed by Mossbauer and X-ray spectroscopies, J. Magn. Magn. Mater. 484 (2019) 291–297, https://doi.org/10.1016/j.jmmm.2019.04.044.

DOI: 10.1016/j.jmmm.2019.04.044

[19] Yunasfi Yunasfi, Mashadi Mashadi, Ade Mulyawan, Wisnu Ari Adi, Synthesis of NiLaxFe(2–x)O4 system as microwave absorber materials by milling technique, J. Electron. Mater. 49 (12) (2020) 7272–7278, https://doi.org/10.1007/s11664-020-08489-w.

DOI: 10.1007/s11664-020-08489-w

[20] Y. Slimani, B. Unal, M.A. Almessiere, A. Demir Korkmaz, Sagar E. Shirsath, Ghulam Yasin, A.V. Trukhanov, A. Baykal, Investigation of structural and physical properties of Eu3+ ions substituted Ni0.4Cu0.2Zn0.4Fe2O4 spinel ferrite nanoparticles prepared via sonochemical approach, Results Phys. 17 (2020) 103061, https://doi.org/10.1016/j.rinp.2020.103061.

DOI: 10.1016/j.rinp.2020.103061

[21] M.K. Kokare, N.A. Jadhav, Y. Kumar, K.M. Jadhav, S.M. Rathod, Effect of Nd3+ doping on structural and magnetic properties of Ni0.5Co0.5Fe2O4 nanocrystalline ferrites synthesized by sol-gel auto combustion method, J. Alloy. Compd. 748 (2018) 1053–1061, https://doi.org/10.1016/j.jallcom.2018.03.168.

DOI: 10.1016/j.jallcom.2018.03.168

[22] M.M.L. Sonia, S. Anand, V.M. Vinosel, M.A. Janifer, S. Pauline, A. Manikandan, Effect of lattice strain on structure, morphology and magneto-dielectric properties of spinel NiGdxFe2−xO4 ferrite nano-crystallites synthesized by sol-gel route, J. Magn. Magn. Mater. 466 (2018) 238–251, https://doi.org/10.1016/j.jmmm.2018.07.017.

DOI: 10.1016/j.jmmm.2018.07.017

[23] L. Guo, Y. He, D. Chen, B. Du, W. Cao, Y. Lv, and Z. Ding, Hydrothermal Synthesis and Microwave Absorption Properties of Nickel Ferrite/Multiwalled Carbon Nanotubes Composites. Coatings,11 534 (2021). https://doi.org/ 10.3390/coatings11050534.

DOI: 10.3390/coatings11050534

[24] Blesa M C, Amador U, Moran E, Menendez N, Tornero J D, Rodriguez-Carvajal J, Synthesis and characterization of nickel and magnesium ferrites obtained from alpha-NaFeO2 Locality: synthetic,, Solid State Ionics 63 (1993) 429-436.

DOI: 10.1016/0167-2738(93)90140-x

[25] B. H. Toby, R. B. Von Dreele. GSAS II the genesis of an open-source all-purpose crystallography software package. J. Appl. Crystallogr. 46 (2013) 544–549.

DOI: 10.1107/s0021889813003531

[26] V. K. Chakradhary, A. Ansaria, and M. J. Akhtara, Design, synthesis, and testing of high coercivity cobalt doped nickel ferrite nanoparticles for magnetic applications. J. Magn. Magn. Mater., 469 (2019) 674-680.

DOI: 10.1016/j.jmmm.2018.09.021

[27] D. A. Vinnik, V. E. Zhivulin, D. P. Sherstyuk, A. Yu. Starikov, P. A. Zezyulina, S. A. Gudkova, D. A. Zherebtsov, K. N. Rozanov, S. V. Trukhanov, K. A. Astapovich, A. S. B. Sombra, D. Zhou, R. B. Jotania, C. Singh, and A. V. Trukhanov, Ni substitution effect on the structure, magnetization, resistivity and permeability of zinc ferrites, J. Mater. Chem. C, 9, 5425 (2021).

DOI: 10.1039/d0tc05692h

[28] Y. E. Gunanto, H. Sitompul, M. P. Izaak, Y. Sarwanto, and W. A. Adi, Microwave Absorbing Material of Ba0.95La0.05Fe12-2xZnxTixO19 (x = 0; 0.5; and 1.0) with Broadband Characteristic at X-band Frequency, J. Eng. Technol. Sci., Vol. 54, No. 2, 220222 (2022). https://doi.org/10.5614/j.eng.technol.sci.2022.54.2.2.

DOI: 10.5614/j.eng.technol.sci.2022.54.2.2
