Optimized 750V SiC MOSFETs for Electric Vehicle Inverter Operation

Abstract:

We report an AEC-Q101-qualified 750V, 15 mΩ planar SiC MOSFETs with a long short circuit withstand time (SCWT) of > 9μs at V_DS=400V and V_GS=15V and a low specific on-resistance (R_ON,SP) of 2.1 mΩ.cm² at V_GS=15V designed for xEV traction inverter applications. The R_DS₍_on) at V_GS=15V increases from 15mΩ at 25 °C to 21 mΩ at 175 °C. A low turn-on (E_ON) and turn-off (E_OFF) switching energy loss of 95.5μJ and 67μJ at I_DS=75A, V_DS=400V was measured at 25 °C. The gate oxide lifetime at worst case operating fields of 5MV/cm is >> 20 years.

By email View Pdf

You might also be interested in these eBooks

International Conference on Silicon Carbide and Related Materials ICSCRM 2022

View Preview

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 945)

Pages:

67-70

DOI:

https://doi.org/10.4028/p-6yitf5

Citation:

Cite this paper

Online since:

May 2023

Authors:

Arash Salemi*, Bob Zhu, Phong Bui-Quang, Yu Ding, Kiran Chatty, Alvin Liu, David Sheridan

Keywords:

AECQ-101, E_OFF, E_ON, R_DS(on), R_ON,SP, Short Circuit Withstand Time (SCWT), SiC MOSFET, TDDB, V_th

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0

Citation:

* - Corresponding Author

References

[1] D. Xing et al., "Design Strategies for Rugged SiC Power Devices," Proceedings of the 2019 IEEE International Reliability Physics Symposium (IRPS), pp.1-5

DOI: 10.1109/IRPS.2019.8720557

Google Scholar

[2] D. Xing et al., "1200-V SiC MOSFET Short-Circuit Ruggedness Evaluation and Method to Improve Withstand Time," Proceedings of the 2022 IEEE Journal of Emerging and Selected Topics in Power Electronics (JESTPE)

DOI: 10.1109/JESTPE.2022.3144995

Google Scholar

[3] A. Agarwal et al, "Switching and Short-Circuit Performance of 27 nm Gate Oxide, 650 V SiC Planar-Gate MOSFETs with 10 to 15 V Gate Drive Voltage," Proceedings of the 2020 IEEE International Symposium on Power Semiconductor Devices and ICs (ISPSD), pp.250-253

DOI: 10.1109/ISPSD46842.2020.9170151

Google Scholar

[4] A. Bhalla et al, "Ultra-high speed 7mohm, 650V SiC half-bridge module with robust short circuit capability for EV inverters," Proceedings of the 2019 IEEE International Symposium on Power Semiconductor Devices and ICs (ISPSD), pp.191-194

DOI: 10.1109/ISPSD.2019.8757666

Google Scholar
